Hydro-cyclone And Cyclone Classifier Hydraulic Classification With High Efficiency
Hydrocyclone is a separation equipment with high efficiency which utilizes centrifugal field to separate two-phase fluid, and it has been applied in classification, thickening, dewatering, desliming, separation, washing and other processes.
Flat Bottom Hydrocyclone Volute Feeding Pre-Classifying Hydrocyclone
| Specifications | Diameter(mm) | Inlet Pressure(MPa) | Capacity(m3/h) | Cut Size(μm) |
|---|---|---|---|---|
| FX840 | 840 | 0.04-0.15 | 500-900 | 74-350 |
| FX710 | 710 | 0.04-0.15 | 400-550 | 74-250 |
| FX 660 | 660 | 0.04-0.15 | 160-450 | 74-220 |
| FX610 | 610 | 0.04-0.15 | 200-300 | 74-200 |
| FX500 | 500 | 0.04-0.2 | 140-240 | 74-200 |
| FX400 | 400 | 0.04-0.2 | 100-170 | 74-150 |
| FX350 | 350 | 0.04-0.2V | 70-160 | 50-150 |
| FX300 | 300 | 0.04-0.2 | 45-90 | 50-150 |
| FX250 | 250 | 0.04-0.3 | 40-80 | 40-100 |
| FX200 | 200 | 0.04-0.3 | 25-40 | 40-100 |
| FX150 | 150 | 0.04-0.3 | 14-35 | 20-74 |
| FX125 | 125 | 0.04-0.3 | 8-20 | 20-50 |
| FX100 | 100 | 0.04-0.3 | 8-20 | 20-50 |
| FX75 | 75 | 0.1-0.4 | 4-10 | 10-40 |
| FX50 | 50 | 0.1-0.4 | 2-5 | 7-40 |
| FX25 | 25 | 0.1-0.6 | 0.3-1 | 5-20 |
| FX10 | 10 | 0.1-0.6 | 0.05-0.1 | 1-5 |
Slurry is fed to cyclones through inlet in tangential or involute direction (depending on feeding way of the inlet head). Under centrifugal force, large particles will move downwards along outer swirling flow and be discharged through apex as underflow while fine particles will move upwards through inner swirling flow and be discharged from apex finder as overflow.
1.Closed circuit grinding.
2.Mineral Classification.
3.Concentrate or Tailings Thickening,Dewatering.
4.Tailings damming and filling.
5.Without motion and power unit,it needs to match with relevant slurry pump.
6.Hydro Cyclone Separator is mainly used in ore dressing industry for classifying, sorting, thickening and desliming.
We often attend international mining processing exhibitions and conferences to deliver better services.
America
EXPONOR CHILE in Antofagasta,Chile
EXTEMIN in Arequipa,Peru
EXPOMINAS MEXICO in Acapulco,Mexico
Asia&Russia
Mining World in Moscow, Russia
UGOL ROSSII & MINING in Novokuznetsk, Russia
Mining World in Alma-Ata, Kazakhstan
Mining Week in Karaganda, Kazakhstan
Iron and Steel Summit in Chhattisgarh,India
Note:Other exhibitions and conferences information will be updated according to customers’ demand.
In recent years, we focus more and more on international market and often dispatch excellent engineers to serve abroad. They help customers with optimum mineral processing solution, improve customer’s efficiency and reduce costs. We will keep expanding our service team and build more targeted team.
- Haiwang is a leading supplier of hydrocyclone and services to the global coal preparation industry, mineral processing industry, FGD in power plant, fertilizer industry and so on.
- Haiwang specializes in world-class hydrocyclone, high frquency vibrating screent and systems. Haiwang invests heavily in developing new products and solutions to meet the important future energy and emissions challenges of our customers.
- Q Do you have testing facilities?
- A Yes, our factory has all kinds of testing facilities, and I could send their pictures and test documents to you.
- Q Will you arrange installation and training?
- A Yes, our professional engineers will guide on installation and debugging at site and provide training as well.
- Q Do you offer guarantee for the products?
- A Yes, we offer one year warranty for the product
- Q How to contact us?
- A Send your inquiry details in the below,click "send" Now!
