water and oil hydrocyclone filter ,hydrocyclones factory from china

Haiwang Hydrocyclone is a separation equipment with high efficiency which utilizes centrifugal force field to separate particles.

Technical Feature

  • New
  • Centrifugal Classifier
  • 98%
  • Shandong, China (Mainland)
  • Haiwang
  • FX25
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$100~20

PRIMARY PARAMETERS

Condition
New
Type
Centrifugal Classifier
Production Capacity
98%
Place of Origin
Shandong, China (Mainland)
Brand Name
Haiwang
Model Number
FX25
Voltage
220V/380V
Power(W)
1.1kw
Dimension(L*W*H)
7000*2000*3000 Mm
Weight
750kg
Certification
ISO9001
Warranty
1year excluding spare parts
After-sales Service Provided
Engineers available to service machinery overseas
Product name
water and oil hydrocyclone filter
Brand
HaiWang
Diameter (mm)
25
Maximum Feeding Size (mm)
0.2
Inlet pressure Range (MPa)
0.1-0.6
particle separation(um)
0.3-1
Capacity (m3/h)
5-20
Application
Ore, Copper, Gold, Water, Oil
Keywords
hydrocyclone

DETAIL DESCRIPTION

Our Product

water and oil hydrocyclone filter ,hydrocyclones factory from china

Description of Haiwang Hydrocyclone
Haiwang Hydrocyclone is a separation equipment with high efficiency which utilizes centrifugal force field to separate particles. Haiwang has been focused on research,development and manufacture of cyclone for nearly 30 years. We are one of the leading cyclone brand manufacturers in the world for the moment.
Haiwang Hydrocyclone has been widely applied in ferrous and non-ferrous metal mines, non-metal mines, coal mines, electric power environmental protection, chemicals & fertilizers, oilfields, construction and other fields.
Haiwang cyclones’ workmanship have become very mature in mine industry application like grinding & classification, thickening, dewatering, desliming, fine material classification as well as tailings backfill, damming and stacking and also has leading technical advantages in the industry.

Introduction of Cyclone   :


Hydrocyclones is also called cyclone separator.Hydrocyclones include hydrocyclone desander(10 in. cone) and hydrocyclone desilter(4 in. cone),which used to separate sand and silt from the drilling fluid.

A hydrocyclone has two exits on the axis: the smaller on the bottom (underflow or reject) and larger at the top (overflow or accept). The underflow is generally the denser or thicker fraction, while the overflow is the lighter or more fluid fraction. Centrifugal pump is used to pump the drilling fluids from mud tank into the set of hydrocyclones.


 Hydrocyclone :

Specification
Diameter (mm)
Maximum Feeding Size  (mm)
Feed Concentration Range (g/L)
Inlet pressure Range (MPa)
Capacity (m3/h)
Cut size (mm)
FX150
150
1.5
50-150
0.10-0.30
15-25
0.04-0.10
FX200
200
2
50-150
0.10-0.30
20-35
0.04-0.10
FX250
250
3
50-150
0.10-0.30
30-60
0.04-0.12
FX300
300
5
50-150
0.10-0.20
50-80
0.04-0.12
FX350
350
6
50-150
0.10-0.20
70-120
0.06-0.16
FX380
380
6
50-150
0.10-0.20
100-160
0.06-0.16
FX450
450
10
50-150
0.08-0.20
160-220
0.10-0.20
FX500
500
10
50-150
0.08-0.20
180-250
0.10-0.20
FX610
610
12
50-150
0.08-015
200-300
0.10-0.20
FX660
660
16
50-150
0.08-0.15
250-400
0.15-0.25
FX710
710
16
50-150
0.08-0.15
350-500
0.15-0.25
FX900
900
22
50-150
0.06-0.15
700-1000
0.20-0.30
FX1000
1000
25
50-150
0.06-0.15
800-1100
0.20-0.40
FX1100
1100
25
50-150
0.06-0.15
900-1200
0.20-0.40
FX1250
1250
28
50-150
0.06-0.15
1000-1300
0.20-0.40

Patented Hydrocyclones :

Hydrocyclone Separator on exhibition :


2. Advantages of Cyclone  :

(1)Serialization, large-scale, specifications: FX150 - FX1250 (mm), cut size: 4 microns - 400 microns.
2)Various wear-resisting materials: High alumina ceramic, polyurethane, ceramic composite materials. We can produce suitable hydrocyclone according to client’s demand or working condition
(3)Personalized structure design: We own multifarious patent structure and advanced   technology at    abroad  and domestic.

3. Application of Cyclone  :


Hydrocyclone has been widely applied in classification, thickening, dewatering, desliming, separation, washing and other processes in ferrous and non-ferrous metal mines, non-metal mines, chemical mines, and it also has been widely applied in coal slime classification, thickening, dewatering, desliming and other processes.


                      Hydrocyclone for chemical mines

                           Hydrocyclone for metal mines


4. Principle of Cyclone   :

Slurry is introduced under pressure through the tangential or involute entry (depending on feeding way of the inlet head) into the hydrocyclone body. Under centrifugal force, large particles will move downwards along outer swirling flow and be discharged through apex as underflow while fine particles will move upwards through inner swirling flow and be discharged from vortex finder as over flow.

Our Service

1.Localized Service

Worldwide offices and agents provide localized sales and technical service.

2.Professional technical service
Professional technical team provide optimum solutions and early stage laboratory tests.

3.Perfect after sales service
Assembly, commissioning, training services by professional engineer.

4.Prompt Delivery
Good production capacity and spare parts stock realize fast delivery.

Our Packing
Packing Details
Cyclone Gas Solid Separator will packing with Standard export container or as required.



 Delivery Time



Within 5-25 days after Cyclone Gas Solid Separator order confirmed.
Our Company

Haiwang Technology was founded in 1989 which is located in Weihai,China.


Haiwang is the leading supplier of mining machinery and mineral processing EPC.

Haiwang has been committed to meet international standards, and has sales and technical service network all over China and set up agencies in more than ten countries,such as Russia, Australia, Peru, Chile, and India,etc.

Our aim is to let mineral processing plant feel our professional,convenient and reliable services,we hope to communicate and cooperate with friends at home and abroad to seek common development and prosperity.

Our FAQ
   Question
1. Are you a factory or trading company ?
We are a factory.
we can also provide ample tests, mine design, equipment manufacture, after-sale service, etc.
2. Where is your factory located?

     Can I visit there?
Our factory is located in Weihai City, Shandong Province, China.

All our clients, from home or abroad, are warmly welcome to visit us !

3. How does your factory do regarding quality control?
Quality is priority.
Haiwang people always attach great importance to quality controlling from the very beginning to the very end.
Our factory has gained ISO9001:2008 authentication.

If you are interested with our products, please don't hesitate to contact us.

We would appreciate if you could describe your requirement according to below questions.


1.Which machine do you need?


2.What is your raw material plan to process? (Such as limestone, granite or iron ore, etc.)
 And What's the maximum size of your raw minerals

3.The capacity you need?

(100 tons per hour or 2000 tons per day?)

4.Your contact information.

(Both Email and phone number are essential, we could provide our better help.)

Now, please click the following contact to send us email !
