The vacuum rotary drum filter is the most widely used type filter in mineral processing industry, finding application both where cake washing is required and where it is unnecessary.
The drum is mounted horizontally and is partially submerged in the filter trough, into which the feed slurry is fed and maintained in suspension by agitators. The periphery of the drum is divided into compartments, each of which is provided with a number of drain lines, which pass through the inside of the drum, terminating at one end as a ring of ports which are covered by a rotary valve to which vacuum is applied. The filter medium is wrapped tightly around the drum surface.
As the drum rotates, each compartment goes through the same cycle of operations, the duration of each being determined by the drum speed, the depth of submergence of the drum, and the arrangement of the valve. The normal cycle of operations consists of filtration, drying, and discharge, but it is possible to introduce other operations into the basic cycle, such as cake washing and cloth cleaning.
Model | Filter area (m2) | Filter plate diameter(m) | Main size (LxWxH) m | Weight(t) | Power(kw) |
BY-1 | 1 | 1.52 | 1.7x1.5x1.5 | 1.4 | 5.28 |
BY-2 | 2 | 1.52 | 1.9x1.5x1.5 | 2.1 | 5.4 |
BY-4 | 4 | 1.52 | 2.5x2.5x2.5 | 2.6 | 6 |
BY-6 | 6 | 1.52 | 2.8x2.9x2.5 | 2.9 | 7.3 |
BY-9 | 9 | 1.52 | 3.1x2.9x2.5 | 3.5 | 12.36 |
BY-12 | 12 | 1.52 | 2.96x2.9x2.5 | 4.5 | 13.08 |
BY-15 | 15 | 1.92 | 3.56x2.9x2.5 | 4.9 | 13.8 |
BY-18 | 18 | 1.92 | 3.86x2.9x2.5 | 5.3 | 14.52 |
BY-21 | 21 | 1.92 | 4.16x2.9x2.5 | 5.7 | 15.24 |
