Slurry press filter for juice and wine with hydraulic pressing

The filter press is widely used in mining, food, pharmaceutical, petroleum, textile, printing and dyeing, paper making, sewage treatment, etc solid-liquid separation industries.

Technical Feature

  • New
  • Automatic
  • 99.9%
  • Henan, China (Mainland)
  • Remont
  • MT series
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$5~50

PRIMARY PARAMETERS

Condition
New
Automatic Grade
Automatic
Production Capacity
99.9%
Place of Origin
Henan, China (Mainland)
Brand Name
Remont
Model Number
MT series
Voltage
380V or as customer requirement
Power(W)
2.2KW-7.5KW
Weight
1.5-65 tons
Dimension(L*W*H)
According to models
Certification
ISO
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
Name
press filter
Color
As requested
Filer plate materials
Polypropylene
Working pressure
0.6Mpa
Design temperature
u226480u2103 or customized
Filter plate size
800-2000mm
Cake thickness
30mm
Filter area
1-1000 square meters
Service
12 month after sale service and online guiding
Package
Wooden cases

DETAIL DESCRIPTION

Product Description
Item Name
Slurry press filter for juice and wine with hydraulic pressing
Filter cloth material
cotton, dacron, nylon, polyester fibers, etc
Plate Type
Chamber, plate frame, membrane, etc
Operation
Manual, semi-automatic, fully automatic
Plate Material
PP,  cast iron, rubber
Plate Size
320, 450,630,800,1000, 1250, 2000
Frame Material
Q235 carbon steel
Max. Filter Area
2000㎡
Technical Parameters
Model
Filter Area
(㎡)
Plate Size
(mm)
Filter Chamber Volume(l)
Plate No.(pcs)
Frame No.
(pcs)
XAG30/870-U
30
870×870
498
23
XAG50/1000-U
50
1000×1000
776
27
XAG80/1250-U
80
1250×1250
1560
29
XAG200/1500-U
200
1500×1500
3809
49
XAG600/2000-U
600
2000×2000
11901
85
XAZ30/870-30U
30
870×870
460
23
XAZ50/1000-30U
50
1000×1000
736
28
XAZ100/1250-30U
100
1250×1250
1468
36
XAZ200/1500-35U
200
1500×1500
2998
49
XAZ600/2000-40U
600
2000×2000
8926
85
BAY4/450-30U
4
500×500
60
9
10
BAY15/630-30U
15
630×630
226
18
19
BAY30/890-35U
30
890×890
524
23
24
Detailed Images
Application
The filter press is widely used in mining, food, pharmaceutical, petroleum, textile, printing and dyeing, paper making, sewage treatment, etc solid-liquid separation industries. Detailed as: ceramic, glaze waste water, gelatin, edible oil, vinegar, chemicals, food processing, pharmaceuticals, leather tanneries, sewage treatment plants, sugar, fertilizers,petro chemicals. Many oil plants, such as rapeseed, cotton seeds, soybean, shelled peanut, flax seeds, sunflower seeds and palm kernel, etc. Medium and small oil refinery, oil mill and private oil squeezing workshop. Any needs about solid liquid separation, contact Apple freely.
Workshop
Our Service
FAQ
