Introduction:
GP tailings dewatering screen concentrates the tailing slurry first and then dewaters treated materials on the vibrating dewatering screen, where more than 85% water contain is removed. For its strong expertise of the design and manufacture, LZZG hire experts in designing andmanufacturing it for two years. It is widely used in dehydrating iron ore, copper ore, gold ore, aluminum ore, etc.


Working principle:
GP series mine tailing screen is driven by two vibrating motors, which makes the screen sieve move to-and-fro on line to achieve the filtering purpose. With the vibration of the screen, the concentrated tailings materials are continuously threw up and down on the screen, the materials are loosen and crashed to the sieve, the small size materials are filtered away from the sieve holes. Finally it reaches the aim of classifying, dehydrating and desliming.

Technical:
1 Reduce a huge investment for building tailings pond
2 Remove the potential danger of dam-break, landslide and infiltration of traditional tailing ponds
3 Can be used in areas where water conservation is critical and any water loses can jeopardise plant performance.
4 Dry stacking is suited to areas of high seismic activity as the construction of retention embankments is prevented.
5 For cold climates, dry stacking prevents pipe freezes and frosting problems with conventional impoundments.
6.Vibrator is in eccentric unit structure, which is easy to disassemble and maintain,
7.Bearing adopts special bearing vibration equipment,which avoids early damage caused by heat.
8.Screen surface adopts polyurethane mesh, high opening rate and resilience is convenient for dehydration.
9.Polyurethane screen with long lifetime, fixed and reliable screen, which can protect screen box side plate not affected by material.
10.Screen adopts rail type to install, which is convenient for maintenance and replacement.
11.The beam surface is coated with anti-wear coating, which can prevent beam premature from premature broken.
12.Adopt steel coil spring to reduce vibration, which minimizes the dynamic load.
13.Adopt finite element analysis software,which can ensure strength, stiffness and reasonable stress of screen frame. And it also has characters such as lightest weight and minimum energy consumption.
14.User can allocate equipment with chassis and feed box, which is convenient for installation and debugging.
15.Main welding structures adopt surface treatment.

Specification:
