Name:GK horizontal scraper discharge centrifuge
Other Names:GK centrifuge
Selling Point:automatic operation; stable running; convenient operation and maintenance; high product output;
Simple Description:
Properties and uses:
Other Names:GK centrifuge
Selling Point:automatic operation; stable running; convenient operation and maintenance; high product output;
Simple Description:
- a horizontal filtering centrifuge with automatic cycle and scraper discharge.
- Screen washing, feeding, separating, washing, dehydrating and discharging can be carried out with full-speed running.
- Adopts to solid-liquid separation of suspensions that contain fine solid particles, and is especially suitable for solid crystal grains that do not have high requirements for the shape of edges,such as polyvinyl chloride, caustic soda, starch and other materials in chemical industry, plastics, fertilizers, food and other industries.
- Excellent dehydrating performance
Properties and uses:
- PLC Control for long-distance monitoring, touch-screen operation and human-machine dialogue for easy maintenance and operation
- Continuous operation and intermittent discharging
- Action elements with automatic electric-hydraulic control
- Safety protection:includes rotation speed monitoring, over-vibration protection, cover opening protection, motor overload and overhear protection, dual control with both mechanical and electrical for scraper
- Welded machine case, strong and rationally design structure
- All seals are made of the fluorous rubber and silicon rubber
- Independent hydraulic station can be installed separately, convenient to repair
- Floating platform with rubber vibration-absorbing foundation; liquid-damping vibration absorber is also available with excellent effects of absorbing effects, ensures stable operation of the centrifuge and reducing hazards imposed to the equipment and environment from the centrifuge vibration
- During the process of discharging, the scraper acts, under the impact of it most products are discharged through the blanking hole on the bottom of drum to the outside. The remnant product layer will be removed because of oscillation effect by the influence of automatic shaking-bag mechanism inside the drum.
| Item | Models | ||
| GK1250/50-NB Spiral discharging | GK1250/60-NB Spiral discharging | GK800-NB Spiral discharging | |
| Drum Diameter (mm) | 1250 | 1250 | 800 |
| Drum length (mm) | 500 | 600 | 400 |
| Drum Volume (L) | 230L | 370 | 95 |
| Loading Limited (kg) | 350 | 500 | 120 |
| Rated rotating speed (r/m) | 1200 | 1200 | 1445 |
| Separation factor (ω²r/g) | 1007 | 1007 | 930 |
| Motor Power (kw) | 55 | 55 | 30 |
| Overall dimension (LxWxH) | 2400/3100x2880x1900 | 3450x3300x2500 | 2100x2000x1400 |
| Weight (kg) | 8000 | 9000 | 5000 |
