Aluminium Fin Copper Tube Air Conditioner Evaporator Coil

SpecificationsWe can supply many kinds of galvanized plate condenser, copper tube condenser, copper condenser which used in air conditioner.We can supply many kinds of galvanized plate condenser, copper tube condenser, copper condenser which used in

Technical Feature

  • Shanghai, China
  • 10000PCS/Month
  • L/C, T/T, Western Union, Paypal
  • Air-Cooled
  • Window Mounted Air Conditioners
  • Copper
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$0~15.85

PRIMARY PARAMETERS

Model NO.
Evp-05
Application Field
Automotive Industry
Certification
CE, CCC, Ce, RoHS
Condition
New
Delivery Time
20days
Use
Refrigeration Copper Tube Finned Condenser
HP
1HP-20HP
Capacity
18000-24000 BTU
Usage
Refrigeration System
Indoor Machine Noise
<23dB
China Energy Efficiency Standard
Level 3
Cooling/Heating
Cooling/Heating
Power Source
Gas
Power Type
AC
Trademark
retekool
Transport Package
in Seaworthy Pallets.
Specification
CE
Origin
China
HS Code
8414599099

DETAIL DESCRIPTION

Specifications
We can supply many kinds of galvanized plate condenser, copper tube condenser, copper condenser which used in air conditioner.
We can supply many kinds of galvanized plate condenser, copper tube condenser, copper condenser which used in air conditioner.

Condenser feature:
1: Material: Copper, Aluminium, Galvanized plate
2: Copper pipe: Diamteter 7mm, 7.94mm, 9.25mm etc, inner grooved or smooth tube,
3: Aluminium foil: Hydrophilic or bare,
4: Fin type: Louver fin, flat fin, corrugated fin
5: Distance of fins can be adjusted between 1.8-5.8mm
6: Distance of holes and distance of rows: 25x21.65mm, 19.05x12.7mm, 25.4x22mm, equilateral triangle arrangement.
7: Suitable for R134a, R22, R404a, R407c refrigerant and so on,
8: Different alternative fan available: Mrcro fan, shaded pole or outer rotor fan motor,
9: No less than 3.0 MPA air pressure(nitrogen) leak test
10: Widely used in refrigerator, air conditioner, cold room, display case, ice chest. Water dispenser and other refrigeration industry,
11: We can offer customized services as well,
If any needs, please contact me
copper evaporator,,cold room evaporator,refrigeration part,copper tube aluminum fin refrigeration evaporator,water to air copper heat exchanger


Product name
water to air copper heat exchanger,copper Condenser

Application


Freezer,showcase,water cooler,cold room,heatig equipmnt


Power

1/3HP, 3/8HP, 1/2HP, 3/4HP, 1HP, 1.5HP, 2HP,3HP, 4HP20HP

Materials

Copper tube aluminum fin, galvanized plate

Tube O.D.

7mm. 7.94mm, 9.52mm, 12.75mm, 15.88mm

Aluminum fin

Hydroponic fin or bare fin,Copper fin

Fin type

Flat fin, Window fin, louver fin, Smooth sine wave fin

Fin space

1.3-10mm

Fan Cover

With cover or without cover,with fan motor or without fan motor

Application refrigerant

R417A/R407C/R404A//R410A/R134A, ect.

Feature

Eoxy coating, electrophoresis,sandblasting
Leaking checking 100%


Aluminium Fin Copper Tube Air Conditioner Evaporator Coil Our moulds:


COPPER TUBE DIAMETER

HOLES PITCH  AND ROWS PITCH

FIN SPACE

HOLES ARRAY

FIN SURFACE

FIN EDGE TYPE

DEFROST HEATER

Φ15.88mm

50 X 50mm

4-10mm

EQUILATERAL TRIANGLE

SIN-WAVE&CORRUGATED

FLAT+WAVE

WITH

Φ15.88mm

38 X 33mm

2.5-4mm

EQUILATERAL TRIANGLE

SIN-WAVE&CORRUGATED

FLAT+WAVE

WITH

Φ12.7mm

31.75 X 27.5mm

3-9mm

EQUILATERAL TRIANGLE

SIN-WAVE&CORRUGATED

FLAT+WAVE

WITH

Φ9.52mm

25 X 21.65mm

1.5-6mm

EQUILATERAL TRIANGLE

SIN-WAVE&CORRUGATED

FLAT+WAVE

WITH

Φ9.52mm

31.75 X 27.5mm

2.5-7.5mm

EQUILATERAL TRIANGLE

SIN-WAVE&CORRUGATED

FLAT+WAVE

WITH

Φ9.52mm

25 X 21.65mm

1.5-2.5mm

EQUILATERAL TRIANGLE

LOUVER

FLAT

WITHOUT

Φ7.94mm

25 X 21.65mm

1.5-3.5mm

EQUILATERAL TRIANGLE

FLAT

FLAT+WAVE

WITHOUT

Φ7.0mm

21 X 12.7mm

1.3-1.8mm

EQUILATERAL TRIANGLE

LOUVER

FLAT

WITHOUT


Best regards!
Amanda


tel: 0086-13906387593
Aluminium Fin Copper Tube Air Conditioner Evaporator Coil
