TECHASE-Special Mulit-Plate Screw Press/Sludge Dewatering Machine/Sludge dehydrator for Amyloid Industry

it doesn't need additional water to clean the equipment,so that there is no secondary pollution.

Technical Feature

Shanghai, China (Mainland)

TECHASE

TECH Series

Mulit-Plate Screw Press/Sludge Dewatering Machine/Sludge dehydrator

Send Standard Inquiry

Add Inquiry List

$100~5

PRIMARY PARAMETERS

Place of Origin

Shanghai, China (Mainland)

Brand Name

TECHASE

Model Number

TECH Series

Product name

Mulit-Plate Screw Press/Sludge Dewatering Machine/Sludge dehydrator

Inlet Water Content

Outlet Moisture Content

HS Code/NCM

Supporting Devices

Certification

SGS,ISO,CE

DETAIL DESCRIPTION

TECHASE-Special Mulit-Plate Screw Press/Sludge Dewatering Machine/Sludge dehydrator for Amyloid Industry

Product Description

1. Automatic continuous operation

2. Compact design with flocculation and dewatering

3. Low power and water consumption

4. Low operation cost

5. No filter cloth, no clogging

6. No need for sludge thickener

7. Easy operation and maintenance

8. No vibration and noise

The traditional dewatering equipment are got block.Due to the movement of fixed rings and moving ring,Techase Multi-plate Screw Press allows continuous operation in 24 hours with no blocking.It is especially good at dealing oily sludge.Moreover,it doesn't need additional water to clean the equipment,so that there is no secondary pollution.

Model List of TECH Multi-Plate Screw Press

Model	Dry Solids Capacity	Dimension	Weight	Motor Power
(kg-DS/hr)	(mm)	(kg)	(KW)
	(L)	(W)	(H)	Net	Operating	Total
TECH-101	3-5	2026	951	1170	200	300	0.44
TECH-102	6-10	2026	1052	1170	300	450	0.62
TECH-103	9-15	2029	923	1160	360	520	0.80
TECH-104	12-20	1969	1317	1160	450	700	1.17
TECH-201	9-15	2950	788	1507	400	750	0.70
TECH-202	18-30	2950	1110	1507	600	900	0.95
TECH-203	27-45	2992	1230	1507	850	1300	1.20
TECH-204	36-60	3057	1508	1507	1100	1600	1.63
TECH-301	30-50	3455	1050	1930	1000	1600	1.38
TECH-302	60-100	3580	1398	1930	1500	2300	2.13
TECH-303	90-150	3766	1636	1930	2000	3000	2.88
TECH-304	120-200	4230	2114	2030	2500	3800	3.83
TECH-401	90-150	4830	1245	2264	2000	3500	1.93
TECH-402	180-300	5040	1606	2345	3000	4500	3.03
TECH-403	270-450	5532	2038	2345	4000	7000	4.13
TECH-404	360-600	5432	2636	2345	5000	7500	5.23

Application Industries

Municipal wastewater / domestic wastewater	Petrochemical industry ( oily sludge)
Pharmaceuticals industry / pharmacy	Chemical
Food industry	Eletroplating industry
Textile	Printing and dyeing
Animal husbandry / livestock industry / livestock breeding	Kitchen waste
Industrial wastewater	Machining wastewater
Coking wastewater	Water purification industry
Refuse processing plant / garbage proposal	Landfill leachate / refuse leachate / percolated fluid
Coal chemical industry	Biotechnology / bioengineering / Biological Engineering / bioengineering
Animal slaughter / animal butcher	Rubber
Paper making	Gelatin
Recycled water / reclaimed water	Marsh gas / methane
