Wastewater treatment belt filter press for fruit juice processing

The principal part adopts stainless steel as its material and possesses high strength.

Technical Feature

  • New
  • Automatic
  • 100%
  • Shanghai, China (Mainland)
  • QILEE
  • QTA-500
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$14~5

PRIMARY PARAMETERS

Condition
New
Automatic Grade
Automatic
Production Capacity
100%
Place of Origin
Shanghai, China (Mainland)
Brand Name
QILEE
Model Number
QTA-500
Voltage
380v/220v
Power(W)
730
Weight
660
Dimension(L*W*H)
2150*1050*2350
Certification
CE ISO
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Type
Belt filter press
Belt Width(mm)
500mm
Treating Capacity(m3/hr)
2.0~3.3
Dried Sludge(kg/hr)
30~50
Inlet Consistency(%)
1.5~2.5
Water Content's Rate(%)
75~85
Powder Consumption(kw)
0.73
Dimensions(mm)
2150*1050*2350
Base Dimension L1*W1(mm)
1460*854
Reference Weight(kg)
660

DETAIL DESCRIPTION

Wastewater treatment belt filter press for fruit juice processing

Product Description



 Belt filter press Features:

 1.The principal part adopts stainless steel as its material and possesses high strength. It is rust-less.
 2. The filter cloth imported from Swiss, to provide the best performance and long service life.
 3. Air chamber type automatic deviation correction device is set to assure stable running of the filter cloth.
 4. Great product capability, good washing effect, flexible operation, low containing moisture in cake and low maintain expense
 5. Low energy consumption,high efficiency ,low revolutions,low noise≤75dB(A)
 6. Safety system monitor the entire working environment,automatic stopping devices to satisfy the need of  operation security.



Technical data & External dimensions of  Belt filter press:

Model

QTA-500

QTA-750

QTA-1000

QTA-1250

QTA-1500

QTA-2000

Belt Width(mm)

500

750

1000

1250

1500

2000

Treating Capacity(m3/hr)

Inlet Consistency(s.s.1.5-2.5%)

2.0-3.3

3.0-5.0

4.0-7.0

5.5-9.5

9.5-15.5

13.5-22.5

Dried sludge(kg/hr)

30-50

45-75

63-105

83-143

143-233

203-338

Water Content’s Rate(%)

75-85

75-85

75-85

75-85

75-85

75-85

Powder

Consumption

(HP)

Driving Motor

1/2

1/2

1/2

1/2

1

1

Disposal Agitator Motor

1/4

1/4

1/4

1/2

1/2

3/4

Drum Thickener

1/4

1/4

1/4

1/4

1/2

1/2

Lower Collecting Tray for Pressed Filtrate

Yes

Yes

Yes

Yes

Yes

None

External Dimensions

(Reference)(mm)

L

2150

2300

2350

2350

2900

2900

W

1050

1300

1550

1800

2130

2630

H

2350

2350

2350

2450

2500

2500

Base Dimension L1*W1(mm)

1460*854

1460*1104

1460*1354

1460*1604

2110*1900

2110*2400

Reference Weight(kgs)

660

800

960

1220

1800

2200





Belt filter press Application:

1.Sludge dewatering of various industrial waste water.
2.Sludge dewatering of butchery, husbandry.
3.Slurry and water separation in food& beverage industry, chemical industry, mining and other industries.
4.Sludge dewatering of city sewage, excretion, water purifying industries.



Belt filter press Structure:





Related Products




FAQ

What’s the application scope of sludge dewatering machine ?

It is widely applied in wastewater treatment in industrial, chemical, municipal and so on.

What’s the material of sludge dewatering machine ?

It is SUS304.

What’s the equipment used together with sludge dewatering machine?

Sludge pump, polymer dosing pump, washing pump, air compressor.

How to choose the model?

Advise us the sludge source, treating capacity, solid content rate, then we could choose the suitable model for you. Please put forward if you have special requirements.



Packaging & Shipping

PACKAGE:

Standard export carton packing.

DELIVERY TIME:

3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
