Among all the turbines provided by Runh Power, condensing steam turbines of various capacity are most popular for generating power in power plants. With detailed technical requirement, the engineers of Runh Power would be able to design and manufacture condensing turbines customized to your needs.
Condensing steam turbine refers to a model of steam turbine fitted with a condensed water collector for higher efficiency.
Technical features of condensing turbine include:
-1) Providing a wide range of power for generating electricity (from 3 to 60 MW)
-2) Highly popular in industries such cement factory, steel factory where both steam and electricity are needed from the turbine.
-3)Can be designed to operate in internal vacuum
-4) Additional extraction nuzzle could be added for adjusting steam flow or extracting steam for other purposes
-5)Can be designed to be hydraulically regulated or alternately regulated (both hydraulically and electrically)
| Model | Power (MW) | parameters of admitted steam | ||
| Pressure (MPa) | Temperatura(C.) | Maximum admission of steam | ||
| N3-0.69 | 3 | 0.69 | 395 | 20 |
| N0.75-1.27 | 0.75 | 1.27 | 340 | 5.5 |
| N1.0-1.27 | 1.0 | 1.27 | 340 | 7 |
| N1.5-1.27 | 1.5 | 1.27 | 340 | 11 |
| N1.5-2.35 | 1.5 | 2.35 | 390 | 10 |
| N3-2.35 | 3 | 2.35 | 300 | 19 |
| N4.5-2.35 | 4.5 | 2.35 | 390 | 18 |
| N6-2.35 | 6 | 2.35 | 390 | 25 |
| N3-3.43 | 3 | 3.43 | 390 | 32 |
| N4.5-3.43 | 1.5 | 3.43 | 390 | 23 |
| N6-3.43 | 6 | 3.43 | 435 | 30 |
| N7.5-3.43 | 7.5 | 3.43 | 435 | 37 |
| N10-3.43 | 10 | 3.43 | 435 | 54 |
| N12-3.43 | 12 | 3.43 | 435 | 66 |
| N15-3.43 | 15 | 3.43 | 435 | 80 |
| N18-3.43 | 18 | 3.43 | 435 | 90 |
| N25-3.43 | 25 | 3.43 | 435 | 136 |
| N25-3.43(air-cooling) | 25 | 3.43 | 435 | 140 |
| N30-3.43 | 30 | 3.43 | 435 | 145 |
| N1.5-3.80 | 1.5 | 3.80 | 435 | 9.5 |
| N3-3.92 | 3 | 3.92 | 435 | 17 |
| N6-3.92 | 6 | 3.92 | 435 | 46 |
| N9-3.92 | 9 | 3.92 | 435 | 57 |
| N12-3.92 | 12 | 3.92 | 435 | 77 |
| N6-4.90 | 6 | 4.90 | 435 | 73 |
| N9-4.90 | 9 | 4.90 | 435 | 70 |
| N12-4.90 | 12 | 4.90 | 435 | 68 |
| N15-4.90 | 15 | 4.90 | 435 | 126 |
| N15-5.88 | 15 | 5.88 | 435 | 137 |
| N25-8.83 | 25 | 8.83 | 535 | 202 |
| N50-8.83 | 50 | 8.83 | 535 | 223 |
| N60-8.83 | 60 | 8.83 | 535 | 240 |
Be advised that all the models listed above are basic ones while customized models are available upon your request.
Runh Power does not merely position itself as a supplier of equipment or provider of technical consulting. The real focus of Runh Power is constructing & financing EPC project( Egineering, Purchase & Construction) of power plant.
