Condensing & extracting steam turbines is best known for high power-generating capacity and versatile application in cogeneration. With your detailed technical requirement, the engineers of Runh Power would be able to design and manufacture condensing & extracting turbines customized to your needs.
Condensing steam turbine refers to a model of steam turbine fitted with a condensed water collector for higher efficiency and an steam extracting valve from where steam is extracted for other purposes.
Technical features of condensing turbine include:
-1) Wide range of power: condensing & extracting unit provides a wide range of power for generating electricity (from 1.5 to 60 MW)
-2) Wide industrial application: Highly popular in industries such cement factory, steel factory where both steam and electricity are needed from the turbine.
-3) Easy repurposing: Additional extraction outlet could be added for adjusting steam flow or extracting steam for other purposes
-4) Easy adjustement on the load: Thermal load and electrinical load can be adjusted independently without interfering with one another.
-5) Dual regulation system: Can be designed to be hydraulically regulated or alternately regulated (both hydraulically and electrically)
| model | power/ maximum power (MW) | parameters of admitted steam | parameters of extracted steam | |||
| pressure (MPa) | temperature (Celsius deg.) | maximum steam flow (ton/hour) | pressure (MPa) | rated/maximum steam flow (ton/hour) | ||
| C1.5-2.35/0.490 | 1.5 | 2.35 | 390 | 72 | 0.490 | 40/55 |
| C3-2.35/4.90 | 3/3.3 | 2.35 | 390 | 39 | 0.490 | 12/18 |
| C6-0.981/0.196 | 6 | 0.981 | 270 | 67 | 0.196 | 30/40 |
| C6-2.35/4.90 | 6/6.6 | 2.35 | 390 | 72 | 0.490 | 40/55 |
| C7-3.43-0.490 | 7 | 3.43 | 435 | 72 | 0.490 | 50/60 |
| C7.5-3.43/0.490 | 7.5 | 3.43 | 435 | 81 | 0.785 | 50/60 |
| C12-3.43/0.490 | 12/15 | 3.43 | 435 | 120 | 0.490 | 60/80 |
| C15-3.43/0.490 | 15/18 | 3.43 | 435 | 134 | 0.490 | 60/80 |
| C15-3.43/0.785 | 15/18 | 3.43 | 435 | 143 | 0.785 | 60/80 |
| C25-3.43/1.27 | 25/30 | 3.43 | 435 | 224 | 1.27 | 80/120 |
| C25-3.43/1.57 | 25/30 | 3.43 | 435 | 256 | 1.57 | 100/150 |
| C25-4.90/0.490 | 25/30 | 4.90 | 435 | 215 | 0.490 | 100/150 |
| C25-8.83/0.490 | 25/30 | 8.83 | 535 | 193 | 0.490 | 100/150 |
| C25-8.83/0.785 | 25/30 | 8.83 | 535 | 203 | 0.785 | 100/150 |
| C50-8.83/0.785 | 50/60 | 8.83 | 535 | 345 | 0.758 | 150/200 |
| C60-8.83/0.785 | 25/30 | 8.83 | 535 | 210 | 0.981 | 100/150 |
Be advised that all the models listed above are basic ones while customized models are available upon your request.
