1) High-speed internal cooling, efficient processing
2) Spindle servo motor to accomplish the requirement of synchronous tapping
3) High rigidity, anti-shake resistance, high processing precision
4) Identify the CAD graphic files intelligently, and automatically convert into the processing programm; Support off-line programming
5) The most optimal processing sequencing, the most optimal path control
2) Spindle servo motor to accomplish the requirement of synchronous tapping
3) High rigidity, anti-shake resistance, high processing precision
4) Identify the CAD graphic files intelligently, and automatically convert into the processing programm; Support off-line programming
5) The most optimal processing sequencing, the most optimal path control
| Model | DMH5200/G | DMH5000/2G | |
| work piece | Max. Length x Width (center points of two hole)(mm) | 5200 x5200 | 5000 x 5000 |
| Max. thickness (mm) | 250 | ||
| Worktable | Distribution form of T notch | Double cross shape or logitudinal and d horizontal | |
| Power head | Quantity | 1 | 2 |
| Taper hole of spindle | BT50 | ||
| Max. drilling diameter (mm) | Φ70(based on the spindle form) | ||
| Tapping capacity | M12-M30 | ||
| Rotation speed ( stepless conversion) (r/min) | 50-3000 | ||
| Motor power (kw) | 30 | 2 x 30 | |
| Longitudinal movement of gantry ( X axis ) | Max. stroke (mm) | | 5000 |
| Movement speed (m/min) | 0-8 | ||
| Servo motor power(kw) | 2 x 4.5 | ||
| Transverse movement of power head ( Y axis) | Max. distance between spindles(mm) | 5200 | 5000 |
| Movement speed(m/min) | 0 - 8 | ||
| Servo motor power(kw) | 2 x 3 | ||
| Feeding movement of vertical ram (Z axis) | Max. stroke(mm) | 600 | |
| Feeding speed (m/min) | 0 - 8 | ||
| Servo motor power (kw) | 2 x 3 | ||
| Positioning precision | X axis and Y axis(mm) | ≤ 0.1/ (Full length) | |
| Re-positioning precision | X axis and Y axis(mm) | ≤ 0.05 | |
| Hydraulic system | Hydraulic pump pressure / flux (Mpa) / (L/min) | 7/30 | |
| Motor power of hydraulic pump (kw) | 3.75 | ||
| Conveying and cooling | Type of chip-conveyor | Chain-plate type | |
| Quantity of chip-conveyor | 2 | ||
| Speed of chip-conveyor | 1 | ||
| Motor power of chip-conveyor (kw) | 2 x0.75 | ||
| Motor power of cooling pump(kw) | 4+1.1 | 2 x 4 +2.2 |
