1) Suitable for a variety of deep hole drills, easy to be cooling and chip conveying, high processing efficiency
2) The unique and patented guiding mechanism which prevent the drill from bending and vibrating.
3) Identify the CAD graphic files intelligently, and automatically convert into the processing programm; Support off-line programming
4) The most optimal processing sequencing, the most optimal path control
2) The unique and patented guiding mechanism which prevent the drill from bending and vibrating.
3) Identify the CAD graphic files intelligently, and automatically convert into the processing programm; Support off-line programming
4) The most optimal processing sequencing, the most optimal path control
| Model | DMH3000/2S | |
| work piece | Max. Length x Width (center points of two hole)(mm) | 3000 x 3000 |
| Max. thickness (mm) | 350 | |
| Worktable | Distribution form of T notch | Double cross shape or logitudinal and d horizontal |
| Power head | Quantity | 2 |
| Taper hole of spindle | BT50 | |
| Max. drilling diameter (mm) | Φ70(based on the spindle form) | |
| Rotation speed ( stepless conversion) (r/min) | 50-3000 | |
| Motor power (kw) | 2 x 30 | |
| Longitudinal movement of gantry ( X axis ) | Max. stroke (mm) | 3000 |
| Movement speed (m/min) | 0-8 | |
| Servo motor power(kw) | 2 x3 | |
| Transverse movement of power head ( Y axis) | Max. distance between spindles(mm) | 3000 |
| Movement speed(m/min) | 0 - 8 | |
| Servo motor power(kw) | 2 x 3 | |
| Feeding movement of vertical ram (Z axis) | Max. stroke(mm) | 600 |
| Feeding speed (m/min) | 0 - 8 | |
| Servo motor power (kw) | 2 x 3 | |
| Positioning precision | X axis and Y axis(mm) | ≤ 0.1/ (Full length) |
| Re-positioning precision | X axis and Y axis(mm) | ≤ 0.05 |
| Hydraulic system | Hydraulic pump pressure / flux (Mpa) / (L/min) | 7/30 |
| Motor power of hydraulic pump (kw) | 3.75 | |
| Conveying and cooling | Type of chip-conveyor | Chain-plate type |
| Quantity of chip-conveyor | 2 | |
| Speed of chip-conveyor | 1 | |
| Motor power of chip-conveyor (kw) | 2 x0.75 | |
| Motor power of cooling pump(kw) | 2 x 4 +2.2 |
