Food Vibrating Screen Equipment for Solid-liquid Separation
Ultrasonic Vibrating Screen is a self-contained equipment working on the principle of gyratory motion using low powered motor. High Frequency Ultrasonic Vibrating Screen for Food Grading (XZS)separates bulk solid materials from solids and slurries, utilizing multi-plane, inertial vibration that causes particlesto pass through apertures in the screen or to travel across the screen surface in controlled pathways.
High Frequency Ultrasonic Vibrating Screen for Food Grading (XZS) handles dry or wet screening of particles from 30mm down to 500 mesh in size.
High Frequency Ultrasonic Vibrating Screen for Food Grading (XZS) ranges in diameter from 400mm to 2000mm, with single or multiple screening decks(up to five)
Typical Applications
Dry separation
-Separation of different materials on the basis of their particle shape
-Foods, chemicals, pharmaceuticals, minerals, animal feeds, grains
Dry classification
-Separation of solid particles into precise sized fractions
-Foods, chemicals, minerals and metals, pulp and wood products, pharmaceuticals, fertilizers, abrasives
Solid/Liquid separation
-Dewatering of solids and clarification of liquids
-Foods, chemicals, pulp
Solids classification in liquid medium
-Separation of solids into sized fraction in a liquid medium
-Chemicals, minerals, pulp and paper, ceramics, waste disposal
Foods: Barley flour, bread crumbs, candies, cereals, coconut shell powder, dried milk, dry potato powder, ground almonds, ground coffee, instant coffee powder, meat meal, nuts, pea grading, powdered cheese, powdered eggs, salt, seeds&grains grading and cleaning, rice bran, soya flour, spices, starch, sugar; Fruit juice, syrup.
Main Features
Small volume with easy moving
High efficiency with compact structure
Easy operation and maintenance
Long screen life, easy&quick screen cloth exchange
Equipped with anti-blinding device(bouncing balls), as well as dust-proof cover
ISO9001: 2008, CE certification
Ultrasonic Vibrating Screen is a self-contained equipment working on the principle of gyratory motion using low powered motor. High Frequency Ultrasonic Vibrating Screen for Food Grading (XZS)separates bulk solid materials from solids and slurries, utilizing multi-plane, inertial vibration that causes particlesto pass through apertures in the screen or to travel across the screen surface in controlled pathways.
High Frequency Ultrasonic Vibrating Screen for Food Grading (XZS) handles dry or wet screening of particles from 30mm down to 500 mesh in size.
High Frequency Ultrasonic Vibrating Screen for Food Grading (XZS) ranges in diameter from 400mm to 2000mm, with single or multiple screening decks(up to five)
Typical Applications
Dry separation
-Separation of different materials on the basis of their particle shape
-Foods, chemicals, pharmaceuticals, minerals, animal feeds, grains
Dry classification
-Separation of solid particles into precise sized fractions
-Foods, chemicals, minerals and metals, pulp and wood products, pharmaceuticals, fertilizers, abrasives
Solid/Liquid separation
-Dewatering of solids and clarification of liquids
-Foods, chemicals, pulp
Solids classification in liquid medium
-Separation of solids into sized fraction in a liquid medium
-Chemicals, minerals, pulp and paper, ceramics, waste disposal
Foods: Barley flour, bread crumbs, candies, cereals, coconut shell powder, dried milk, dry potato powder, ground almonds, ground coffee, instant coffee powder, meat meal, nuts, pea grading, powdered cheese, powdered eggs, salt, seeds&grains grading and cleaning, rice bran, soya flour, spices, starch, sugar; Fruit juice, syrup.
Main Features
Small volume with easy moving
High efficiency with compact structure
Easy operation and maintenance
Long screen life, easy&quick screen cloth exchange
Equipped with anti-blinding device(bouncing balls), as well as dust-proof cover
ISO9001: 2008, CE certification
| Model | Nominal diameter | Sieve diameter | Effective screen area | Maximum feed size | Screen size | Layers | Vibration times | Power |
| (mm) | (mm) | (m² ) | (mm) | (mesh/inch) | (Rpm) | (KW) | ||
| XZS-400 | 400 | 340 | 0.09 | < 10 | 2-500 | 1-5 | 1500 | 0.18 |
| XZS-600 | 600 | 530 | 0.22 | < 10 | 1500 | 0.25 | ||
| XZS-800 | 800 | 720 | 0.4 | < 20 | 1500 | 0.55 | ||
XZS-1000 | 1000 | 900 | 0.63 | < 20 | 1500 | 0.75 | ||
| XZS-1200 | 1200 | 1100 | 0.95 | < 20 | 1500 | 1.1 | ||
| XZS-1500 | 1500 | 1400 | 1.5 | < 20 | 1500 | 2.2 | ||
| XZS-1800 | 1800 | 1710 | 2.3 | < 30 | 1500 | 3 | ||
| XZS-2000 | 2000 | 1910 | 2.86 | < 30 | 1500 | 4 |
