Sludge dewatering centrifuge separator application:
Suitable for solid-phase particle size 0.005 ~ 15mm, the concentration of 1 to 40% solid suspension of all types of temperature ≤100 ºC phase dehydration, liquid phase separation and clarification, liquid and solid separation and particle grading. Especially for cloth regeneration and concentration difficulties, changes in the larger suspension particles are separated. Resins such as polyvinyl chloride, ammonium sulfite, barium carbonate, strontium sulfate, lithopone, starch, diatomaceous earth, gypsum, bauxite, soy protein, peanut protein, fruit juices, drinks, vegetable oil, citric acid, blood meal, titanium white powder, kaolin and other processing drilling mud and concentrate dewatering fine coal dewatering, waste oil net lees, mineral classification treatment, municipal wastewater treatment plant sludge and dyeing sludge, paper sludge and other industrial wastewater treatment.
Feature
1Weld hard alloy or spray hard alloy for wear protection
2 Full automatic and sealed continuously operation make the maintenance more easlier less cost
3 Larger output capacity
4 Compact design and saving room
Structural Diagram ------------------------------------------------------Reyes Machinery
Solid liquid centrifuge separator
- workload light
- high quality
- user friendly
- automatic continuous operate
- solid liquid centrifuge separator:
| Model | Diameter (mm) | Bowl speed (rpm) | Length (mm) | G-force | Capacity (m3/h) | Main motor power (kw) | Assistant motor power (kw) | Weight (kg) | Overall size (L × W × H)(mm) |
| PNX409 | 250 | 5500 | 850 | 3493 | 0.2-2 | 15 | 4 | 1020 | 2500 × 650 × 760 |
| PNX-414 | 355 | 4000 | 860 | 3175 | 1~10 | 18.5 | 7.5 | 2035 | 2765 × 920 × 1060 |
| PNX-416 | 355 | 4000 | 1160 | 3175 | 1~15 | 18.5 | 7.5 | 2122 | 3065 × 920 × 1060 |
| PNX-418 | 355 | 4000 | 1460 | 3175 | 1~25 | 22 | 7.5 | 2222 | 3365 × 920 × 1060 |
| PDC-1655 | 420 | 3000 | 1450 | 2113 | 10~30 | 55 | 15 | 4600 | 4080 ×1100 × 1420 |
| PDC-17-4 | 420 | 3600 | 1680 | 3042 | 3~15 | 30 | 7.5 | 5165 | 3331 × 990 × 1066 |
| PDC-18-4.4 | 450 | 3300 | 2000 | 2739 | 10~20 | 37 | 11 | 2739 | 4000 × 1120 × 1239 |
| PDC-20 | 500 | 3200 | 2000 | 2860 | 5~45 | 55 | 11 | 4400 | 4489 × 1160 × 1350 |
| PDC-21 | 540 | 2800 | 2000 | 2366 | 15~50 | 45 | 15 | 5290 | 4587 × 1285 × 1368 |
| PDC-24 | 620 | 3200 | 2480 | 3555 | 15~60 | Hydraulic station 90 | 8000 | 4650 × 2010× 1200 | |
| PDC-28HH | 720 | 2200 | 2400 | 1975 | 15-80 | 110 | 37 | 9393 | 4800 ×1350 × 1500 |
More parts show of the decanter centrifuge:
Productive process-------------------------------------------------------Reyes Machinery
Workshop-------------------------------------------------------------------Reyes Machinery
Best Service for You
1) 7day*24hours Hot-line & Email Service
2) Your inquiry related to our products or prices will be replied in 24hours.
3) Well-trained and experienced staffs to answer all your questions in fluent English.
4) Abundant spare parts in stock are available to provide.
5) Our technicians could be dispatched for overseas service.
6) Your workers could get trained in our factory.
FAQ
1.What's the application of centrifuge?
This machine is widely used in many fields such as environmental, pharmaceutical food, chemical industry for separation/washing/dewatering . It can separate almost all liquid and solid with proper feature.
2.How to clean the machine?
The machine has self-cleaning function. When the processing is finished, you just put one button and the machine will do the cleaning automatically.
3. How to choose the machine material?
For the material, we have stainless steel 304, 316 and 321 for your option. Generally SS304 is used. If there's suspension with corrosion, then SS 321 /316 or Ti is needed.
4.What's the capacity of the machine?
Firstly we have different model with different capacity for this machine.
Secondly, the capacity will be customized according to concentration of the suspension. Higher the concentration, lower the capacity.
5. How is the processing result?
The finished cake moisture and solid lost rate is based on the material feature. And different machine just brings different processing capacity. Also we can offer testing service to get realistic results.
