Description
Horizontal spiral centrifuge is one of our company main products. According to the requirement of the material used, we design the horizontal spiral centrifuge with one motor, two motors driving. At the same time, we design two motors separately on both sides of the machine and motors on the same place of the machine. We also develop three column horizontal spiral centrifuge, used in the separation of coal tar oil, water, slag in the industry, in petrochemical in the separation of oil, water, slag.
Main motor drive at full speed rotating drum, material put into spiral continuously by feed tube, evenly distributed to the spiral discharging port. Under centrifugal force, solid content settles to the drum wall and is pushed out cone drum slag notch by the spiral pusher. Liquid is overflow along the spiral to the drum big end. It form big end set out liquid and small end set out solid.
Structure
Horizontal screw centrifuge is for 0.002-3mm material for clarification, separation, dehydration, or classify 1um-5um solid phased particles. It is wide application range, work continuously, large processing capacity, low cost, convenient maintenance and so on. It is the best equipment for separating solid-liquid. It is widely used in chemical industry, light industry, medicine, food, paper making, mining and other industries.
1.Differential with high precision, compact structure, smooth operation.
2.Main bearing of imported bearings, to ensure the accuracy of the operation.
3.The part contacting with material is made of stainless steel.
4.The machine is equipped with a variety of safety overload protection devices, to make sure safety in production.
5.The machine system has two types, regular and explosion proof, to meet the different requirement.
6.Large length to diameter ratio, high speed, many angels of drum cone structure
7.Spiral pusher surface adopts hard alloy materials, against abrasion powerfully
8.According to the customer's desire, the frame can develop to low center of gravity, high bracket and
move.
9.Spiral structure with BD board is used for the concentration dehydration of activated sludge and difficult separate materials
10.According to customer's requirement, the machine can equip double frequency conversion and intelligent automatic control system.
Structural Diagram ------------------------------------------------------Reyes Machinery
Feature of wheat starch decanter centrifuge
- workload light
- high quality
- user friendly
- automatic continuous operate
- APPLICATION
Food: Fruit and Vegetable juices, Starch, Protein, Molasses, Stillage
Oils and Fats: Fish oil, Gelatine
Environmental protection/Recycling: Drilling mud, Industrial wastewater, Municipal wastewater
Minerals: Graphite, Kaolin, Bentonite
Technical Paramter:
Two phase decanter centrifuge:
| Model | Diameter (mm) | Bowl speed (rpm) | Length (mm) | G-force | Capacity (m3/h) | Main motor power (kw) | Assistant motor power (kw) | Weight (kg) | Overall size (L × W × H)(mm) |
| PNX409 | 250 | 5500 | 850 | 3493 | 0.2-2 | 15 | 4 | 1020 | 2500 × 650 × 760 |
| PNX-414 | 355 | 4000 | 860 | 3175 | 1~10 | 18.5 | 7.5 | 2035 | 2765 × 920 × 1060 |
| PNX-416 | 355 | 4000 | 1160 | 3175 | 1~15 | 18.5 | 7.5 | 2122 | 3065 × 920 × 1060 |
| PNX-418 | 355 | 4000 | 1460 | 3175 | 1~25 | 22 | 7.5 | 2222 | 3365 × 920 × 1060 |
| PDC-1655 | 420 | 3000 | 1450 | 2113 | 10~30 | 55 | 15 | 4600 | 4080 ×1100 × 1420 |
| PDC-17-4 | 420 | 3600 | 1680 | 3042 | 3~15 | 30 | 7.5 | 5165 | 3331 × 990 × 1066 |
| PDC-18-4.4 | 450 | 3300 | 2000 | 2739 | 10~20 | 37 | 11 | 2739 | 4000 × 1120 × 1239 |
| PDC-20 | 500 | 3200 | 2000 | 2860 | 5~45 | 55 | 11 | 4400 | 4489 × 1160 × 1350 |
| PDC-21 | 540 | 2800 | 2000 | 2366 | 15~50 | 45 | 15 | 5290 | 4587 × 1285 × 1368 |
| PDC-24 | 620 | 3200 | 2480 | 3555 | 15~60 | Hydraulic station 90 | 8000 | 4650 × 2010× 1200 | |
| PDC-28HH | 720 | 2200 | 2400 | 1975 | 15-80 | 110 | 37 | 9393 | 4800 ×1350 × 1500 |
More parts show of the decanter centrifuge:
Productive process-------------------------------------------------------Reyes Machinery
Workshop-------------------------------------------------------------------Reyes Machinery
Best Service for You
1) 7day*24hours Hot-line & Email Service
2) Your inquiry related to our products or prices will be replied in 24hours.
3) Well-trained and experienced staffs to answer all your questions in fluent English.
4) Abundant spare parts in stock are available to provide.
5) Our technicians could be dispatched for overseas service.
6) Your workers could get trained in our factory.
FAQ
1.What's the application of centrifuge?
This machine is widely used in many fields such as environmental, pharmaceutical food, chemical industry for separation/washing/dewatering . It can separate almost all liquid and solid with proper feature.
2.How to clean the machine?
The machine has self-cleaning function. When the processing is finished, you just put one button and the machine will do the cleaning automatically.
3. How to choose the machine material?
For the material, we have stainless steel 304, 316 and 321 for your option. Generally SS304 is used. If there's suspension with corrosion, then SS 321 /316 or Ti is needed.
4.What's the capacity of the machine?
Firstly we have different model with different capacity for this machine.
Secondly, the capacity will be customized according to concentration of the suspension. Higher the concentration, lower the capacity.
5. How is the processing result?
The finished cake moisture and solid lost rate is based on the material feature. And different machine just brings different processing capacity. Also we can offer testing service to get realistic results.
User's site:
Package show:
