Ladder tray type FRP Material GRP cable ladder
XQJ Ladder tray has the cables supported by a traverse bar, similarly to the rungs of a ladder. Ladder and ventilated trays may have solid covers to protect cables from falling objects, dust, and water. Tray covers for use outdoors or in dusty locations may have a peaked shape to shed debris including dust, ice or snow.
-Features
1. High strength, insulativity, inflaming retarding and corrosion resisting
2. Ligth weight
3. Low cost
4. Easy to install
5. With long lifetime
-Specification
Main parts of XQJ Cable Ladder Tray:
1.Straight segments
2.Horizontal elbows(Various shapes including tees and crosses.)
3.Supporting arm
4.Hanger bracket
5.Connection accessories
XQJ Ladder tray has the cables supported by a traverse bar, similarly to the rungs of a ladder. Ladder and ventilated trays may have solid covers to protect cables from falling objects, dust, and water. Tray covers for use outdoors or in dusty locations may have a peaked shape to shed debris including dust, ice or snow.
-Features
1. High strength, insulativity, inflaming retarding and corrosion resisting
2. Ligth weight
3. Low cost
4. Easy to install
5. With long lifetime
-Specification
Model | b(mm) | h(mm) | Weight(kg) | |
| XQJ-T-01 | -6-2 | 200 | 60 | 13.7 |
| -10-2 | 100 | 17.96 | ||
| -15-2 | 150 | 25.97 | ||
| -6-3 | 300 | 60 | 14.85 | |
| -10-3 | 100 | 18.84 | ||
| -15-3 | 150 | 28.31 | ||
| -6-4 | 400 | 60 | 23.2 | |
| -10-4 | 100 | 27.29 | ||
| -15-4 | 150 | 33.25 | ||
| -6-5 | 500 | 60 | 25.7 | |
| -10-5 | 100 | 29.8 | ||
| -15-5 | 150 | 35.75 | ||
| -6-6 | 600 | 60 | 28.22 | |
| -10-6 | 100 | 32.3 | ||
| -15-6 | 150 | 38.02 | ||
| -6-8 | 800 | 60 | 31.96 | |
| -10-8 | 100 | 37.76 | ||
| -15-8 | 150 | 44.46 | ||
| Remark:h=60,100 is single row connect hole, h=150 is double row connect holes |
Main parts of XQJ Cable Ladder Tray:
1.Straight segments
2.Horizontal elbows(Various shapes including tees and crosses.)
3.Supporting arm
4.Hanger bracket
5.Connection accessories
