Detailed Description:
Dairy separator is the most important equipment in dairy industry. Mainly used in the skim milk, butter, casein, cheese production, anhydrous butter production process, such as centrifuge concentrate, and removal of foreign impurities in the milk. Similar materials can also be used for clarification and purification.
This product absorbs the advantage of the same kind foreign. Product in Germany and Russia. All the parts that may contact the feedstock are made of stainless steel. Availably reduce the chemical effect of the feedstock and the machine spare parts.
Power drive adopts the traction clutch, Transfer power by the fluid, start reliably, prevent overland. The bearings used the machine are SKF grade in Sweden., guarantee working precision of the machine.
The separator adopts the PLC automatic control system, can carry out automatic de-slugging, ability of fitness is stronger, automatic degree is high. Easy to adjust, worker labor strength is opposite to ease, the solids content ratio in the mixture fluid is widely When working, the sealing water 7 is bumped Into the sealing room 6, rising the sliding piston, and sediment ejection hole 3 is shutted down. Then, Milk
To be processed are fed to the bowl from feeding pipe 1, Under the effects of centrifugal force, the solids which has heavier density is collected on the bowl wall, After a while, the opening
Water 7 is bumped into the opening room 5, falling the sliding piston, open the sediment ejection hole 3, impurities are deluged from the bowl. The lighter liquid (fat) flow along the inner side of the discs into the passage in the upper distributor, the lighter product is discharged from the machine by the lower
Centripetal pump8. The heavier liquid(skim milk) flow along another passage, discharged from the machine by the upper centripetal pump2. Thus the milk is separated well. The separator adopts self de-slugging and centripetal pump. Thus the machine can work continuously for a long time, attain good separation effects in long run.
| Model number | NRSD5 | NRSD10 | NRSD30 | NRSD50 |
| Product capacity( L/h) | 500 | 1000 | 3000 | 5000 |
| Bowl diameter( mm) | 230 | 300 | 400 | 475 |
| Bowl speed (rpm) | 8000 | 7320 | 6500 | 6000 |
| Motor power (KW) | 1.5 | 4 | 7.5 | 11 |
| Sludging-mode | PLC automatic control | PLC automatic control | PLC automatic control | PLC automatic control |
| Output pressure (KPa) | 100-350 | 100-350 | 100-350 | 100-350 |
| Temperature ( .C) | 40-45 | 40-45 | 40-45 | 40-45 |
| Fat in skim milk(%) | ≤0.04 | ≤0.04 | ≤0.04 | ≤0.04 |
| Weight(KG) | 120 | 450 | 650 | 1100 |
| Dimension(mm) | 700*550*800 | 800*600*1250 | 1100*650*1550 | 1100*700*1600 |
| Model | NRSDH100 | NRSDH150 | NRSDH200 |
| Product capacity (L/h) | 10000 | 15000 | 20000 |
| Bowl diameter(mm) | 540 | 620 | 800 |
| Bowl speed(rpm) | 6000 | 5800 | 5000 |
| Motor power(KW) | 15 | 22 | 30 |
| Sludging-mode | PLC automatic control | PLC automatic control | PLC automatic control |
| Output pressure(KPa) | 100-350 | 100-350 | 100-350 |
| Temperature( .C) | 40-45 | 40-45 | 40-45 |
| Fat in skim milk(%) | ≤0.04 | ≤0.04 | ≤0.04 |
| Weight (KG) | 1500 | 1800 | 2200 |
| Dimension(mm) | 1400*1000*1800 | 1600*1400*1850 | 1800*1500*1900 |
FAQ
1.Is your price competitive?
My price is not the lowest in China as for high quality,but we promise for the same quality and collocation,my price is the most favorite,for the same price ,my quality is definitely superior.to other brand.
2.Do you have OEM service?Do you supply the parts?
Yes,we do,as long as you provide us your drawing and detailed requirements.
3.Do you have agent or service center in my country?
We have some partnership in several countries as Indonesia,Brazil,USA etc,you are warmly welcomed to work as our agent,at this moment,we have no service centers abroad,but we can provide overseas spot and online technical service in time.
4.How can we easily find out the most fit centrifuges?
We have experienced engineer team to help you make the model selection,as long as you provide us the detailed processing material characteristics.
5.What payment mode you accept?
TT , LC at sight or others .
Note: The prodcution capacity is based on water only, just for reference. Different feeding solution will of different production capacity.
