People will crash and separate the mature crops depend on their physical properties, then obtain strach. So the strach separator is the key in the process of strach extraction.
In the strach separation process, the separator rotates in high speed then creates the centrifugal force, so the separation efficiency is improved. At the sam time maximize the production efficiency. We devote ourselves to make Longda starch separator to the most professional and efficient in starch processing industry, it collects all the advantages of various separator such as small vibration, larage capacity, stable running and so on. It's mainly used in preconcentration strach, separation of starchand gluten, concentration of gluten(protein), clarify of process water in the after step and so on.
Features of products:
1. Big diameter of drum, large area of disk, strong capability of production(separaton), excellent effect of separation.
2. Adopting top-suspension driving, which makes the separation with high rotation stability, and largely improves the using the using life of driving system.
4. Adopting big nozzles, which has big feed capability, reduces the chances of block, assuring the continuous production.
5. Fitted with hydraulic system for lifting drum, which makes more esily to check the drum and replace nozzles.
6. The material of drum adopts imported high-strength corrosion-proof stainless steel, which assures the safety and stability of separator.
7. This machine can be started up when no load.
8. This machine can treat the materials with various concentration without internal adjustment.
9. Fitted with inner circulation system, which keeps the stability of separation and good to adjust and control accurately.
10. Operating easily, the workers can master the operation regulation in short.
Technical Datas:
(Made) | Treat- ment Capacity (T/H) | Spe- ed of Drum | Motor Power (Kw) | weight (kg) | Outline Size (mm) |
DPF 445 | 20-35 | 4500-5200 | 30 | 1400 | 1284 *1407 *1457 |
DPF 520 | 25-45 | 4650 | 37 | 1550 | 1617 *1240 *1565 |
DPF 600 | 30-60 | 2850-4800 | 75/55 | 3500 | 2000 *1000 *2050 |
DPF 800 | 22-115 | 2750-3300 | 132/110 | 7800 | 2800 *1500 *2200 |
DPF 935 | 45-225 | 2250-3050 | 250/220 | 11000 | 3200 *1800 *3100 |
DPF 960 | 45-250 | 2250-3000 | 250/220 | 11500 | 3200 *1800 *3100 |
DPF 1000 | 45-300 | 2250-2950 | 300/220 | 12000 | 3200 *1800 *3100 |
DPF 1170 | 50-500 | 2200-2800 | 315/250 | 15000 | 3500 *2000 *3300 |
