Description:
Cassava /tapioca starch ,as the one of the most important starch,is very huge consumption in whole world.Our disc separators play essential role in this field,with big capacity,stable operation,it is the necessary equipment in the cassava processing line,we can not only provide the singe disc separators,but also could provide the whole producing line ,commonly,1kg cassava could obtain 0.2kg cassava starch
Competitive Advantages:
- with high speed,
- accurate dynamic balancing,
- long time with low vibration,
- safety and security.
- Continuous working
- Nozzle discharging
Cassava /tapioca's Abstraction Technics Flowing Chart
1, Main equipment: Use washer to get rid of smudginess, 80% skin will be peeled off
2, Crush is to break the structure of tapioca,hence to separate starch from the its roots.
3, Filtration is to wipe off the sediment, and upgrade the concentration of Starch-milk to 6Be`.
4,Refining: tapioca enters into separator after impurity removing ,commonly, two sets of disc-nozzle centrifuge in series are to be used to upgrade the concentration of starch-milk to 20-22Be`
5, Dehydration:we usually use scraper centrifuge to process and the liquid in starch- milk will be less than 35% for further drying.
Starch Refining and Separating Technics Flowing Chart:
This technique adopts two sets of Model DPF disc-nozzle centrifuge in series, concentration of starch-milk will reach peak to 20-22Be` after separating.
REYES also provide the whole producing line for cassava starch
Technical Parameters:
| Model | 450 | 600 | 800 | 950 |
| Bowl Speed(rpm) | 5200 | 4800 | 3300 | 3050 |
| Capacity(T/H) | 20~35 | 30~60 | 22~115 | 45~225 |
| Power(kw) | 30 | 55 | 110 | 220 |
| Dimension L×W×H(mm) | 1284×1407×1457 | 2000×1000×2050 | 2800×1500×2200 | 3200×1800×3100 |
Working Diagram
Installation note:
1. Need sufficient space to install and maintainance
2. The install foundation should be smooth and fixed.
3. Between the foundation and frame, you have to install the vibration reducer gasket
4. All pipes connected with the machine should be the hose.
Application:
- wheat starch,
- cornstarch,
- sweet potato starch,
- cassava starch
- potato starch,
- bleaching earth
- recovering pulp
Package show:
After Sales
*12 months guarantee period from machine arriving date.
*Abundant spare parts in stock are availble to provide.
*Our technicians could be dispatched for overseas service.
*7*24 hours technical consultation.
*Your workers could get trained both in our factory and yours.
*Routine tracing till the machine work properly will be done timely.
*We will remind you to do the normal maintenance.
*Your suggestions or any comments & reflection would be treated in priority.
*Marketing team will visit you during our visit to your country if you require.
