Description:
The starch disc separator is high speed and continuous nozzle discharge type. They are mainly used for protein separation in the starch industry, like corn starch, sweet potato starch, cassava starch and potato starch, etc. for purifying starch, previous concentration, separating protein and recovering starch in starch production and also separating two-phase liquid-solid, recovering concentration or purifying, such as bleaching earth, recovering pulp, waste water, etc.
All the parts of the separator contacting the materials are made of stainless steel, therefore it meets the requirement of food hygiene. The design production and acceptance check are complied with JB/T6419 "Disc Starch Separator".
In today's art, 3 phase decanter is mainly used for separate starch A, B starch gluten and liquid pentosan,AT present, this 3phase decanter is mainly produced by FLOTTWEG, WESTFALIA ,.
Commonly, before separation, wheat starch B with 1.5-3Be waste, and after the nozzle separator treatment, the underflow concentration is 3-10Be.
Competitive Advantages
- with high speed,
- accurate dynamic balancing,
- long time with low vibration,
- safety and security.
- Continuous working
- Nozzle discharging
REYES also provide the whole producing line for cassava starch
Technical Parameters:
| Model | 450 | 600 | 800 | 950 |
| Bowl Speed(rpm) | 5200 | 4800 | 3300 | 3050 |
| Capacity(T/H) | 20~35 | 30~60 | 22~115 | 45~225 |
| Power(kw) | 30 | 55 | 110 | 220 |
| Dimension L×W×H(mm) | 1284×1407×1457 | 2000×1000×2050 | 2800×1500×2200 | 3200×1800×3100 |
Working Diagram
Installation note:
1. Need sufficient space to install and maintainance
2. The install foundation should be smooth and fixed.
3. Between the foundation and frame, you have to install the vibration reducer gasket
4. All pipes connected with the machine should be the hose.
Application:
- wheat starch,
- cornstarch,
- sweet potato starch,
- cassava starch
- potato starch,
- bleaching earth
- recovering pulp
Package show:
After Sales
*12 months guarantee period from machine arriving date.
*Abundant spare parts in stock are availble to provide.
*Our technicians could be dispatched for overseas service.
*7*24 hours technical consultation.
*Your workers could get trained both in our factory and yours.
*Routine tracing till the machine work properly will be done timely.
*We will remind you to do the normal maintenance.
*Your suggestions or any comments & reflection would be treated in priority.
*Marketing team will visit you during our visit to your country if you require.
