High Capacity Disc Stack Centrifuge Separator
After the water and algae are separated you will get a hard paste that can then be hydraulically pressed and the oil harvested.Product Description
Model RPDB313VC03 separator is the newest generation separator, mainly used to purify of . The model is also used to separate similar material in the industry of juice,beverage,Chinese traditional medicine and chemical industry etc.
The machine adopts automatic control, it has the advantages of high efficiency, low materiel consumption, convenient operation and economic maintenance cost. It adopt small piston structure for gaining variable discharging capacity,and PLC control both partly and fully discharging in order to get rid of sediment.
The clear liquid is pumped out by centripetal pump, the sludge is discharged automatically and partly.
The machine is one kind of rotary machine with high speed, After accurate dynamic balancing, it can run for long time with low vibration, safety and security.
The design, product and acceptance are conformed to the standard of JB/T8103.3 "Disc Separator Part 3disc separator".
Techinical Parameter
discharging type | variable capacity discharging | ||
fresh water capacity | l/h | ≥25000 | |
impurity in sweetwater after separating | mg/kg | 1 | |
outlet pressure of clear liquid | MPa | ≤0.2 | |
motor power | kW | 22(380V/50Hz/3P) | |
N.W. | kg | 1580 | |
dimension | L×W×H | 1479mm×1289mm×1583mm | |
export | dimension of package | L×W×H | 1900mm×1570mm×2050mm |
G.W. | kg | 1800 |
Assembly parts :
Workshop of our factory :
If you have any questions about our machine , please don't hesitate to contact with me freely ,thanks .
