Specification:
Pressure:0-4.0Mpa
Capacity:0-2000m³/h
Viscosity:1-3000mm²/s
Temperature:-20-300 degrees
| Model | Pressure | 1450r/min | 950r/min | 720r/min | |||||||||||||
| 30cst | 75cst | 150cst | 300cst | 450cst | 750cst | 1500cst | 2500cst | ||||||||||
| m³/h | kw | m³/h | kw | m³/h | kw | m³/h | kw | m³/h | kw | m³/h | kw | m³/h | kw | m³/h | kw | ||
| 5.0-52 | 1.0 | 50.7 | 30 | 53.9 | 30 | 55 | 30 | 55.5 | 37 | 33.8 | 22 | 34 | 22 | 25.3 | 30 | 25.4 | 30 |
| 1.25 | 49.1 | 30 | 53.1 | 37 | 54.4 | 37 | 55.1 | 37 | 33.5 | 30 | 33.7 | 30 | 25 | 30 | 25.1 | 37 | |
| 1.6 | 46.9 | 37 | 52 | 45 | 53.7 | 45 | 54.6 | 45 | 33.1 | 37 | 33.3 | 37 | 24.7 | 30 | 24.7 | 37 |
Advantage:
1, The delivery of liquid smooth, no pulsation, no mixing, small vibration, low noise.
2, Self-priming performance is very strong, multiphase, gas rate is not higher than 80%, the sediment concentration is less than 500g/m3.
3 ,External bearing structure, using independent lubrication, can transport a variety of non lubricating media.
4, The use of synchronous gear drive, two rotors do not touch, even if a short time idling is no harm.
5, Pump body with heating cover, can transport all kinds of clean or contain small particles of solid viscosity or high viscosity medium (general particle diameter is less than 0.12-0.2mm)
6, The correct selection of materials, and even the transmission of many corrosive media.
7 ,Double suction structure with no axial force on the rotor.
8, The shaft end adopts mechanical seal or bellows mechanical seal, with long life, less leakage, a wide range of characteristics.
Application:
1. Oil: used as oil and gas, water, trace fine solid particles of multiphase pump and oil pump.
2. Shipbuilding: used as a ship loading pump, bilge sweeping and sewage treatment, main engine lubricating pump, fuel oil pump.
3 . Petrochemical industry: as a variety of resins, pigments, paraffin wax, paint, ink, latex, all kinds of oil, crude oil, heavy oil, such as loading and transportation pumps.
4 . Thermal power plant: used as heavy oil and crude oil delivery pump, main engine lubricating oil pump.
5.Food industry: used as alcohol, honey, syrup, fruit juice, animal and vegetable oil, milk, slurry oil delivery pump.
Hebei Hengsheng pump manufacture Co., Ltd is a professional manufacture of positive displacement pump in China.The company located in BoTou Hebei province and has a modern garden-style factory.Our company is specialized in the pump related designing,casting,production,sales and services. HeBei HengSheng pumps was founded in 1973,the birthplace of first KCB series gear pump in China.HengSheng pump took the lead in the pump industry through the 9001 quality management system certification. In addition,we established the national class B product test station and has many top level testing equipment in our workshop to test every pump performance and trace the quality of each pump .
Our company has been extremely popular in the market.HengSheng pump as a number of material source market of petrol China and Sinopec.The known product manufacture and marine product manufacture.All of our pump model has certificated by ABS CCS BV for marine application.HengSheng is mainly engaged in the production of gear pumps and screw pumps of 33 series and 4500 specification.and the annual production capacity which is up to 45,000 sets of pumps that are widely use in oilfield,chemical industry,power industry,ships,metal industry and food industry.
Experienced more than 40 years,HengSheng has become the largest scale,the most varieties,leading technology and strongest processing and testing ability in domestic pump industry.HengSheng has exported to over 35 countries such as US,Germany,Indonesia,Saudi Arabia and Colombia
We have patented products whidch is gear pumps, screw pumps, piston pumps.
If you are interested in our pump,please send inquiry to us!
