Fermenting equipment 1000L fermentor/conical fermenter/fermentation tank

Fermenting is the process during which the yeast transforms the wort into beer.

Technical Feature

  • Fermenting Equipment
  • New
  • Shandong, China (Mainland)
  • Honglin
  • Honglin Series
  • Beer
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$45~6

PRIMARY PARAMETERS

Processing
Fermenting Equipment
Condition
New
Place of Origin
Shandong, China (Mainland)
Brand Name
Honglin
Model Number
Honglin Series
Processing Types
Beer
Voltage
Custom design
Power(W)
15-70Kw Depends
Dimension(L*W*H)
Capacity
Weight
200KG-2000KG
Certification
CE ISO TUV
Warranty
5 Years
After-sales Service Provided
Engineers available to service machinery overseas
Name
Beer brewing equipment
Function
Brewing beer
Keywords
1000l fermenter
Control system
Semi-automatic
Heating method
Steam/Electric/Direct Fire
Usage
Brewery Pub Hotel
Capacity
50l-5000l
Material
SUS304/Red copper
Inner Thickness
3mm
Outer Thickness
2mm

DETAIL DESCRIPTION

Fermenting equipment 1000L fermentor/conical fermenter/fermentation tank

Product Description

 Instruction of 1000l Fermenter:

Stainless steel craft beer fermenter(fermentation tanks) are also called CCT’s (Cylindrical Conical Tanks), FV’s (Fermentation Vessel), primary fermenters or unitanks as they are used both for fermenting and lagering.Fermenting is the process during which the yeast transforms the wort into beer. Lagerings takes place after fermenting and is the time given to the beer to stabilize and age after fermenting.

NameFermenting equipment 1000L fermentor/conical fermenter/fermentation tank
FunctionBeer fermentation or maturation
Warranty5 years
Keywords1000l fermentor



Specifications of fermentation tanks:



Fermentation tank series

Volume in US Gallon

Diameter

Height

100l Fermentation tank

26US Gallon

620mm

1600mm

200l Fermentation Tank

53US Gallon

820mm

1800mm

300l Fermentation Tank

79US Gallon

960mm

1900mm

500l Fermentation Tank

132US Gallon

1010mm

2100mm

1000l Fermentation Tank

264US Gallon

1210mm

2500mm



Complete beer brewing equipment components:



EquipmentComponents
Grain milling unitRoller miller
Brewhouse

Necessary equipment

1.Mash tun 2.Lauter tun 3.Boiling tun 4.Whirlpool tun

5.Boiler 6.Plate heat exchanger 7.Wort pump

Other accessories are available: 1. Ornamental Pipe; 2. Mashing Pipeline; 3. Operating Plateform; 4. Yeast Feeder; 5. Venturi Tube; 6. Butterfly Valve DN40; 7. Butterfly Valve DN32; 8. Soft Pipe; 9. Dregs Rake; 10. Sugar Measuring Cylinder; 11. Saccharimeter;
Fermentation

Fermentation tank

Bright beer tank

Other accessories are available: 1. L-Pipe; 2. Butterfly Valve; 3. Pressure Gage;

4. Solenoid Valve; 5. Vacuum Valve; 6. Cooling Pipe;7. Thermal Insulation Pipe;

Glycol chilling unit1. Ice Water Tank
2. Refrigeration Machine
3. Centrifugal Pump
4. Evaporator
5. Ice Water Pump
6. Relative Pipes and Valves
CIP unit1. Washing Tank
2. Sterilization Tank
3. Pump and Valve
Control box1.Mashing control panel
2.Fermenting control panel
3.Refrigerating Control Panel



. MicroBrewhouse

1.Mash tun, Lauter tun, Boiling Kettle, Whirlpool tun in various combination

2.Hot water tank and cold water tank for optional in special combinations

3.Infusion or decoction brewing methods are designed exactly



Ⅱ.Configuration

(1). Malt Milling Unit

   Particle adjustable rolling crusher

   Flexible or steel auger for optional

(2). Brewhouse Unit

Mash tun, Lauter tun, Boiling Kettle, Whirlpool tun in various combination

Hot water tank and cold water tank for optional in special combinations

Infusion or decoction brewing methods are designed exactly

Stainless steel or Red copper material are popular

Two stages plate heat exchanger for wort cooling

Completely stainless steel integrated work platform

Sanitary and efficiency wort pump

All pipings and fittings





(3). Fermentation Unit

   Standard stainless steel conical cylindrical fermentation tanks

   Single size or double size as brewhouse is common used in microbrewery

   Tanks quantity is exactly calculated by fermentation cycle for various beers

   All manhole, valves, pressure gauges, fittings etc are included





(4). Beer Filter Unit(optional)

    In restaurant or bar, beers are always served as craft beer without filtration

(5).Bright Tank Unit

   Standard stainless steel bright tanks for beer maturation, conditioning, service, carbonation

   Single size or double size as fermenter is common used in restaurant or bar

   Tanks quantity is exactly calculated for various beers and the function

   All manhole, valves, stone, gauges, fittings etc are included

(6). Cooling Unit

    Insulated glycol water tank with or without copper coil for glycol liquid holding and mixing

    Efficiency chillers or refrigerators with fryonto supply cooling energy

    Sanitary centrifugal pump for glycol water recycle among tanks and heat exchanger

    All pipes, fitting, insulation materials are included





(7). Controlling Unit

    Electrical controlling cabinet with temperature, on-off controlling for brewhouse

    Electrical controlling cabinet with temperature, on-off controlling for cooling parts

    Temperature controller, thermocouple, solenoid valves etc are included

    PLC with touch screen panel for special request





Certifications



Packaging & Shipping



1.Wooden case or steel frame.

This method is very good for loading but need extra cost. Also because of the dimensions of the tanks and container, maybe some tanks cannot use them, but can be confirm when talking about the order.

2.Generally will use the stretched film, this is free and also can avoid the scratches. Will use the carton to cover all of the accessory.

Our Services



1.Pre-sales service

Some clients are new in this field, they also no have ideas about how to confirm the configuration list, since we have experience, we can give some suggestions and also other clients for reference, then they will know what they will need exactly.

We also have the process video for the brewing equipment, if the client do not know the process, the video will be sent.

We will give the layout according to the client’s floor plan or their requirements.3D layout also can be provided. This can help the client to get a better understanding about the project.

We will give the detailed diagram of the tanks, this can help the client to know whether this is what they need and also can modify them before placing the order.

2.After-sales service

 When loading the equipment, we will take photos and show them to the client to confirm everything in the container already.

 Another important issue is installation,2 options can be chosen by the clients as follows:

 1). We can send the engineer there for helping the client install debug the equipment, if it is necessary, the engineer also can teach the client how to brewing beer.

 2). We can provide the piping diagram and wire diagram. They are useful for installing. Then the client can install the equipment by themselves.

 3). The sales will contact with the client all the time until the equipment running normally. Once the client need any assistances or need any accessory, the sales will provide them soonest.

Our Cases



FAQ



Q1:What size of building do I need?
For a brewpub, size depends on a lot your yearly volume and how many different types of beer you want to brew.The minimum area request is around 20m2. There are also estimated area requests in our different brewery systems in specification above.
For microbreweries the main factor is yearly volume.For small microbreweries, floor space of 300m2 usually is enough.
About details on your project,we can give you exact dimensions and requirements.



Q2:What utilities do I need for a brewery?
Typically water,electricity and drains are needed.
In general, 3 phase electricity is common and suitable for 220/380/440 voltage with 50/60Hz.The size of the water connection is determined by the size of equipment.
For brewery project, we provide our customers with detailed requirement on the utilities and their respective location.



Q3:Not being a brewer, can i start a brewery?
Yes! There are not so many brewers. Honglin can help you or one of your employees learning how to brew, including familiarizing you with operating brewery equipment, studying recipes, grasping quality control and so on.
Above all, we can also offers a wide variety of services such as project planning, layout design, installation, and after sales services etc.These services are free!



Q4:Where can I get my ingredients?
Almost every country or area can find a supplier for malt,hops,yeast etc. Honglin company can also help to get good quality raw materials here.If you find the ingredients hardly, we can make arrangement to shipped to you.



Q5:Can I brew all types of beer with the Honglin equipment?
Contrary to the open-vessel fermentation system mainly used in Eastern Europe and Germany,all beer styles can be brewed with our system.
