Wet Brewers' Grain Dryer, complete drying system &solution at competitive prices

spent grain is a byproduct of the brewing process.

Technical Feature

  • New
  • Rotary Drying Equipment, drum drying system for wet spent grains
  • Henan, China (Mainland)
  • DL
  • 2212P3
  • Customized
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$150~50

PRIMARY PARAMETERS

Condition
New
Type
Rotary Drying Equipment, drum drying system for wet spent grains
Place of Origin
Henan, China (Mainland)
Brand Name
DL
Model Number
2212P3
Voltage
Customized
Power(W)
90000
Dimension(L*W*H)
12*2.0*2.0m
Weight
18000kgs
Certification
CE ISO
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
capacity
10t/d to 50t/d

DETAIL DESCRIPTION

Product Description

Brewers’ grain/spent grain is a byproduct of the brewing process. Beer begins with a mash of barley (and sometimes other grains) and hot water, which after an hour or so of enzymatic activity, converts the grain’s starch into sugar and is then drained and rinsed to extract that sugar. That’s what the brewer wants: sugar, which is the starting place for fermentation. Left behind are the starchy endosperm, residual protein and whatever residual sugars the brewer couldn’t rinse away. These protein- and fiber-rich leftovers are excellent feed for everything from cows to chickens



We offer complete solutions to retrieve proteins from brewers spent grain from the beer production.

The system includes dryers, screw presses and complete installations for dewatering and drying of by-products from the beer production. Dry spent grains contain 20 to 26% crude protein and are used as a pure natural addition to animal fodder.



Dryer models and major technical parameters

model

DLSG1409

DLSG1415

DLSG1615

DLSG2209/3

DLSG2212/3

DLSG2512/3

DLSG2912/3

capacity(t/d)

7.6

12.7

14.4

22

29.8

35

42.6

water evaporation(t/h)

0.396

0.66

0.75

1.147

1.554

1.84

2.216

Initial moisture (%)

83% Max.

final moisture

10% Max.

drying temperature

270 +/-30 C

total power

30.7

32.7

40.2

78

90

125

135

floor area(m2)

5m×15m

5m×18m

6m×18m

8m×18m

8m×20m

10m×20m

12mx20m





Our Services

 1. Free consultation on technical &commercial issues, provide market evaluation, project feasibility based on each customers' condition.



 2. Provide free drawings at no cost for factory layout, piping & wiring systems, installation plannings,



 3. Free installation, commissioning and operation training services at no costs to customers.



 4. 24/7 aftersales service, free of charge if repair service required within 1 year after installation.
