Fish Flour Separation Centrifugal Equipment

The centrifugal sludge dewatering machine can achieve the integration of three functions: sludge thickening, sludge dewatering and thickened sludge dewatering.

Technical Feature

  • Jiangsu, China (Mainland)
  • Purestar
  • LW
  • Fish Flour Separation Centrifugal Equipment
  • Household Drinking Water Sterilizer
  • Blue
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$10~80

PRIMARY PARAMETERS

Place of Origin
Jiangsu, China (Mainland)
Brand Name
Purestar
Model Number
LW
Product name
Fish Flour Separation Centrifugal Equipment
Application
Household Drinking Water Sterilizer
Color
Blue
Certification
ISO9001
Warranty
One Year
Usage
Liquid Filter
centrifugal type
decanter centrifuge
machine type
horizontal centrifuge
Weight
1000-16000KGS
Material
Stainless Steel

DETAIL DESCRIPTION



Wuxi ShuHang Machinery Science And Technology co.,ltd is located at Xinming Industry Park of Xibei Economic Development Zone which is adjacent to the new mainline of Beijing-Shanghai High-speed Railway and Huning Expressway with convenient traffic. The company is a high-tech enterprise with more than 10,000 square meters area processing workshop that is professional in the integrated development design, processing manufacture and project installation of chemical, foodstuff, pharmaceutical and environmental protection machineries whose core technology and major products are major series products of horizontal spiral decanter centrifuge,Three-phase Separation Horizontal Screw-discharge Sedimentation Centrifuge, complete set of sludge dewatering equipment, PP Melt Blown Filter Cartridge,Active carbon filter device, PP filter cartridge machine



Brief introduction



The centrifugal sludge dewatering machine can achieve the integration of three functions: sludge thickening, sludge dewatering and thickened sludge dewatering. The concentrate dewatering system is consists of 5 parts: (1) sludge feed system, (2) flocculants dosing system;(3)concentrate dewatering system;(4) mud cake delivery system: (5)Serial system electrical control. To adapt to different targeting customers, we provide two different serial system electrical controls; (1) summary type: automatic control in operation; (2) General type: PLC control



Performance Characteristics of large slenderness ration Dewatering Centrifuge



1.    Large slenderness ration L/D:4-4.8, high rotating speed, small differential speed system: the large slenderness ration increase the time of clarification and dewatering in the machine; High rotating speed can strengthen the centrifugal force; Small differential speed can reduce the screw for material mixing, increase the dewatering time, then improve the results of dewatering and clarification. It produces much drier solid waste and much clearer separation liquid.



2.    High torque hydraulic differential: the torque is 2 to 4 times of mechanical differential and it improves the output of solid dehydration.



3.    Hydraulic differential can adjust itself with the load, automatically compensate the power of pushing-material, and get more consistent dry solid waste by two-way squeeze both from centrifugal force and two blades. It can automatically restore the initial differential to avoid putty. It can save 30% on drug and power consumption. The noise is less than 82db.



4.    The initial differential adjustment range is 0-20 r/min.



5.    Drum stag discharge mouth, spiral feeding mouth, pushing blade hot spray welding w2c-65% hard wear-resistant material with the thickness of 3mm. Compared with common fins, it has better wear resistance and there is no need to change it. It has a longer life Sludge Dewatering Solid Bowl Decanter Centrifuge .





Fish Flour Separation Centrifugal Equipment

Warehouse of Product







Sprial







Main Technical Parameters



Machinery differential – the main technical parameter of sludge dewatering centrifuge



Model Type

Drum diameter(mm)

Drum length(mm)

Max speed(r/min)

value(g)

Capaciy(m³/h)

Power(kw)

Weight(kg)

Dimension(mm)

LW250X900-N

250

900

5000

3500

0.5-3

7.5-11

1100

2300X700X1300

LW300X1200-N

300

1200

4500

3400

1-5

7.5-11

1400

3000X900X1300

LW350X1500-N

350

1500

3800

2850

1-8

15-18.5

2200

3500X1000X1300

LW400X1600-N

400

1600

3500

2750

2-10

18.5-22

2400

3800X1000X1250

LW400X1800-N

400

1800

3500

2750

2-12

18.5-22

2500

4000X1000X1250

LW450X1800-N

450

1800

3300

2740

5-20

30-37

3000

4200X1200X1350

LW450X2150-N

450

2150

3300

2740

5-25

30-37

3500

4600X1200X1350

LW500X2000-N

500

2000

3000

2500

8-35

37-45

4000

4650X1300X1500

LW530X2280-N

530

2280

2800

2350

10-50

37-45

4300

4800X1300X1500

LW580X2400-N

580

2400

2600

2200

20-65

45-55

5500

4800X1400X1850

LW650X2600-N

650

2600

2400

2100

20-80

55-75

6500

4900X1450X1650

LW720X2500-N

720

2500

2200

1950

25-90

75-90

7000

5000X1600X1700

LW800X3200-N

800

3200

2000

1800

30-110

90-132

9000

5200X2200X1400







Hydraulic differential – the main technical parameters of sludge dewatering centrifuge



Model Type

Drum diameter(mm)

Drum length(mm)

Max speed(r/min)

value(g)

Capaciy(m³/h)

Power(kw)

Weight(kg)

Dimension(mm)

LW350X1600-NY

350

1600

3800

2850

1-8

15-18.5

2200

3600X1000X1300

LW400X1800-NY

400

1800

3500

2750

2-12

18.5-22

2500

4000X1000X1250

LW450X2000-NY

450

2000

3300

2740

5-25

30-37

3500

4450X1200X1350

LW500X2000-NY

500

2000

3000

2500

8-35

37-45

4000

4650X1300X1500

LW530X2280-NY

530

2280

2800

2350

10-50

37-45

4300

4800X1300X1500

LW580X2600-NY

580

2400

2600

2200

20-65

45-55

5500

4800X1400X1850

LW650X2600-NY

650

2600

2400

2100

20-80

55-75

6500

4900X1450X1650

LW720X2500-NY

720

2500

2200

1950

25-90

75-90

7000

5000X1600X1700









Warmly welcome for your visiting and cooperation!





Visit us by train: 30 minutes from Shanghai.
