It is a special equipment on the basis of traditional net belt dryer.It has stronger pertinency,practiability and high efficiency of energey.The third generation DWT series dryer for vegetable dehydration has been developed.According to the characteristics of raw material to be dried and the process requirements of customers and combined the accumulated experience for more ten years,we have made the most suitable and the best dryer for vegetables dehydration for customers.The series equipment had won CNP,Its patent number is:ZL 99 2 29732X.
 |
| vegetable dryer can meet to dry different vegetables such as, root, halm, leaf, tuberous root, big granule and produce in batch. Meanwhile it can maintain content of nutrition, color, etc of vegetable in most extent. The type raw materials are garlic, cushaw, giantarum, white turnip, yam, bamboo shoot, capsicum, onion, apple, etc. When operation, air will be entered into the dryer and heated through heat exchanger. Being adapted scientific and reasonable cycle method, the hot air will pas through raw materials to be dried on the bed and carry out uniform heat exchange. Under the action of cycle fan, the hot air stream inside each unit of the dryer will carry out hot air cycle. Final air with Iow temperature and high damp will be out. The whole drying process with stably and high effect will be finished |
 |
  |
vegetable Dryer Technical parameters
| Type | DWT1.6-I (fed table) | DWT1.6-II (middle table) | DWT1.6-III (discharge table) | DWT2-I (fed table) | DWT2-II (middle table) | DWT2-III (discharge table) |
| belt width m | 1.6 | 1.6 | 1.6 | 2 | 2 | 2 |
| drying section length m | 10 | 10 | 8 | 10 | 10 | 8 |
| thickness of the material to be covered mm | ≤100 | ≤100 | ≤100 | ≤100 | ≤100 | ≤100 |
| temperature | 50-150 | 50-150 | 50-150 | 50-150 | 50-150 | 50-150 |
| Areae of heat conduction m2 | 525 | 398 | 262.5 | 656 | 497 | 327.5 |
| steam pressureMpa | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 |
| drying time h | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 |
| power kw | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 |
| overall Dim.m | 12×1.81×1.9 | 12×1.81×1.9 | 10×1.81×1.9 | 12×2.4×1.92 | 12×2.4×1.92 | 10×2.4×1.92 |
 |
Our Advantages 3.We can make the machine based on the customer request . 4.For the material for the machine ,we have several kinds of raw material for choice Such as SUS304 ,316L , carbon steel as well as others . 5.For the heating source for the machine , we can make it based on the available facility at customer site ,such steam ,electricity ,gas-furnace and so on. 6.we invited and pointed Professor Arun s. Mujumdar, the lifetime chairman of International Drying Conference and the winner of “Friendship Award” of the Chinese government as our technical consultant as to keep YIBU machine with the world advantage technology; 7.We have R&d team ,and can help customer to design his process of the product . 8. For the motor , we have more choices , such ABB,SEW,Siemens and so on . 9.For the burner , we have choices of Usgas ,Rellio or other international brand . 11.For shaft , we can choose SKF ,Japan NSK bearings.etc . 12.Our machine we can design with explosion proof , dust -free, water-free , sealed circulating . 13. Guarantee /warranty :1year calculating from the day of successful installation and commissioning. 14.Package : wooden packing . Special fumigation -free wooden material . Or according to customer requirement . 15.Product special features : A. Dust-proof ,heat-proof ,oil -proof ,explosion -proof ; B.Green,Environment performance; Our Services Pre-service 1. Introduce the product to the customer in detail, answer the question raised by customer carefully; 2.Make plans for choice according to the needs and special requirements of users in different sectors; Sale service 1. Ensure product with high quality and pre-commissioning before delivery; 2. Delivery on time; 3.Provide full set of documents as customer’s requirements. After-sale service Provide considerate services to minimize clients’ worries. 1.Assist clients to prepare for the first construction scheme; 2.Install and debug the equipment; 3.Train the first-line operators; 4. Examine the equipment;5.Take initiative to eliminate the troubles rapidly; 6.Provide technical support; 7.Establish long-term and friendly relationship. Service commitment 1. Provide clients one-year warranty to make sure the machine work well; 2.We always keep certain inventory level of spare parts, which means the replacements can be sent to you timely; 3.Send every client a preferential quotation. |
