10BAR high pressure compressed air dryer
1. The interface, the unique inclined plane design with simple man-machine, the easily style gate lock, is convenient and rapid.
2. Classic, neat and compact structure design.Science and technology aesthetics-specialization.
3. Pre-cooler of copper gas-gas, the evaporator of copper, more sufficient for exchanging heat.
4. The supper-volume of whirlwind separator can remove water at all.
5. The best parts, the best design, the longest life.
6. All electrical intelligence control, no " ice machine", more reliable and save energy.
Technical specification:
model | NE-0.5 | NE-1 | NE-1.6 | NE-2 | NE-3 | NE-4 | NE-6 | NE-8 |
Free air delivery (m3/min) | 0.7 | 1.2 | 1.6 | 2.6 | 3.8 | 4.5 | 6.8 | 8.5 |
Air connections | G1/2" | G1/2" | G1" | G1" | G1" | G1" | G11/2" | G11/2" |
Motor power(W) | 0.5 | 0.6 | 0.85 | 0.85 | 1.2 | 1.2 | 1.3 | 1.3 |
dimension | 361x344 | 580x400 | 690x440 | 690x440 | 790x440 | 790x440 | 1126x528 | 1126x528 |
weight(Kg) | 38 | 53 | 62 | 65 | 75 | 80 | 170 | 175 |
Voltage frequency | 220V/1/50Hz | 220V/1/50Hz | 220V/1/50Hz | 220V/1/50Hz | 220V/1/50Hz | 220V/1/50Hz | 220V/1/50Hz | 220V/1/50Hz |
Working pressure(Mpa) | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 |
