PW type pump to transmit maize

PW pump to transmit maize is designed by JB2975-8 "centrifugal pump sewage pump" published standard a new series transmit pum. The series pump designed new, the structure new tight, the size small, the high efficiency. This is a high efficient, econmize e

Technical Feature

  • Designed new
  • Structure new tight
  • Size small
  • High efficiency
  • econmize energy
  • impurity
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$500~50000

PRIMARY PARAMETERS

Brand name
TIANMA
Application
starch
Process input material
-
Process output material
-
Place of origin
China
Equipment material
SS & CS
Power (kW)
4-132
Weight (kg)
Depends
Outer dimension (mm)
Depends
Warranty
One year
Delivery
30 days
Main spare parts
-

MODEL SPECIFICATIONS

Model 2 1/2 PW 2 1/2 PW-II 3 1/2 PW 4 PW 6 PW 8 PW 10 PW
Rate of flow(m3/h) 40 80 100 130 330 350 800
Head(m) 32 50 20 25 20 15.5 15
Rotate speed(r/min) 2900 2900 1450 1450 1450 960 960
Eff(%) 45 54 50 51 58 64 60
Motor power(kw) 11 22 15 18.5 37 45 75

DETAIL DESCRIPTION


PW type pump to transmit maize


PW pump to transmit maize is designed by JB2975-8 "centrifugal pump sewage pump" published standard a new series transmit pum. The series pump designed new, the structure new tight, the size small, the high efficiency. This is a high efficient, econmize energy of transmit grain impurity pump.

The pump is single and unitary attraction, liedown cantilever below in 80℃ liquich that contains grain dirty and something with fiber, paper pieces etc. is the liquid of non-obliterate solid body out-standing. (The out-standing solid body size is not allowed 80% of outlet diameter)
