GOJE Factory provide multi-plate mannitol evaporation concentrator alcohol multiple evaporator for industry
1.MVR and TVR joint evaporation
For materials with the concentration of higher than 50%, the MVR-TVR joint evaporation is recommended, which means evaporation and concentration are done in following two steps step 1) MVR evaporation, which concentrates materials to approximately 50%; and step 2) TVR evaporation, which further concentrates 50% of the intermediary materials until a thick concentration of 70% is achieved.
2.Schematic digaram
3.Application
Dairy products | Whole milk and skim milk powder, condensed milk, |
Protein | Soy bean milk, nutritional yeast and fodder yeast, |
Juice | Orange juice and other citrus juice, apple juice, |
Vegetable Juice | Beet root juice, tomato juice, and carrot juice |
Starch products | Glucose, dextrose, levulose, maltose, starch syrup, |
Suger | Liquid suger,refined white suger sweet water,and inulin |
Extract | Coffee and tea extract, hop extract, malt extract, |
Hydrolyzed material | Whey hydrolysates, seasonings, and protein hydrolysates |
Beer | Dealcoholized beer and malt wort |
4.Plate Quality
Fluid Media | |
Stainless steel AISI304,316 | Clean water,stream water,cooking oil,and mineral oil |
Titanium | Sea water,hyrochoric acid,and phosphoric acid |
Hastelloy alloy | Concentrated sulphuric acid,hydrochloric acid,phosphoric acid |
Nickel | High-temperature and highly concentrated caustic soda |
Molybdenum | Dilute sulphuric acid,dilute saline water solution,inorganic water solution |
5.Gasket Quality
NBR | EPDM | Fluororubber | Silicone rubber | |
Fluid Media | Water,sea water.mineral | Hot water,steam, | Acid and alkali fluids | Food,oil fat ethyl alcohol |
Application Temperature | -15~120℃ | -25~140℃ | -5~200℃ | -65~180℃ |
Feature | Easier to replace than the traditional gasket,high pressure, high temperature, longer life, |
Jiangsu S-JE technology Co.,Ltd. is a newly established sub-company of Nanjing Gaojie Light industrial Equipment Co.Ltd. and has an export license. Jiangsu S-JE technology Co.,Ltd. specializes in supplying GSA-F series plate heat exchanger and imported plate; the largest domestic caliber plate condenser at home; semi-welded liquid ammonia evaporator; foreign imports of film and lifting film, falling film evaporator and plate evaporation system engineering services.Our company has experience in exporting heat exchange equipment and evaporating equipment to global. Our main markets are North America, Asia, Middle East and Africa.Now we are also developing new products to expand more market. We have our own designer and R&D group to develop new products and we can also creat new products in accordance with customers’requirements.Our company warmly welcomes all customers to visit our company. We hope to establish long-term and close cooperative relationships with our customers in order to achieve win-win benefits.
Our advantage
First: We have the most complete models plate heat exchanger at home and broad.
Second: We have heat exchanger sub-detachable, semi-welding, full welding, wide flow and irregular flow channel
Three: We have the entire system of integrated evaporation and design strength, the form of the evaporator at home and abroad ,the most full of film, falling film, lifting film series and a dozen different specifications of the model. Separate and semi-welded evaporator plates, equivalent to imported plates.
Four: We have the overall process design capabilities for the biological fermentation industry..
Five: We have heat exchanger and evaporator mold development strength.
