Rotary Pouch Packing Machine
Machine Features:
1. High quality and performance, the frame is made of 150mm thickness 304# stainless steel.
2. Volume changed easy by adjusting handle in the paste filler.
3. Good stable and also good machine exterior
4. Own extensive range in filling productions
5. Easy operate by touch-sensitive screen (Siemens), PLC (Siemens) and electric control system
6. Friendly man-machine interface
7. Speed can be adjusted by frequency conversion within the range.
8. Perfect sealing system
9. Good safety secure and so on
Model | MR8-200G |
Bag type | All type of heat sealable preformed side seal bags, fin seal bags, fin seal bags, gusseted bags,block bottom bags, zip-lock recloseable bags,stand-up pouch with spout pouch, stand-up pouch with zipper pouch, etc |
Bag size | W:80-200mm, L: 100-300mm |
Filling Volume | 5-2500g |
Capacity | 30-60bags/min,depend on type of product and packaging materials |
Accuracy | Error ≤±1% |
Total power consumption | 5KW |
Application | Candy, peanut, coffee bean, pistachio, nuts, sugar, cooked food, grain, granule, solid, seeds, pet food, etc depend on type dosing system selected |
Optional equipment | Dosing assembly, materials bulk feed system, special down, metal detector, check weigher, stream attachment, etc. |
For example:
For common bag For zipper bag
1.bag feeding 1.bag feeding
2.date printing(option) 2.date printing(option
3.opening bag 3.opening zipper
4.filling 1 material 4.opening bag
5.filling 2 material(option) 5.filling material
6.sealing 1 6.close zipper
7.sealing 1 7.sealing 1
8.sealing 2,out putting 8.sealing 2,out putting
The function of working station will be different according to your products
and bags.
1,How many days can finish install all machine ?
Generally need 1 week, finish all install machine, adjustment and training worker.
2,should we pay any cost for engineer?
Yes, for engineer visa cost, accommodation, food, round air-tickets, and subsidy(100USD/day) by buyer.
3,how about warranty?
One year guarantee, defective spare parts can be replaced for free charge by express within this period.
4,if over warranty how to do ?
If over warranty, we also can do service for customer, send to spare parts by express or our engineer
go to your side check and adjust machine. The buyer pay for all charge.
5,do your engineer know english?
Our engineer know english,and every engineer have five years experience adjust, install machine,
our engineer have been to USA,South America,Southeast Asia, Europe, Africa etc.
6, how can we solve the problem when machine have problem?
Usually after first install machine,no bigger problem. If it has small problem,we can take video.Meanwhile
we can call phone or skype face to face teach your engineer how operation and adjust machine by email.
7 ,how many worker ?
Generally the one machine one worker or two worker.
8 ,When engineer can arrive our factory?
Generally after machine arrived, Within one week reached.
Details:
1.Siemens Touch Screen
2.Bag bottom opening device(suitable for stand-up pouch)
3.Full bag check sensor(OMRON)
If you interested our packing machine, pls contact me.
I will recommend most suitable machine for you, according to your information of products.
...
