VFFS feeding, weighing and packing system for candy,seed,potato chips,coffee,peanut,puffy,biscuit,chocolate,nut,yogurt,pet fo

According to different materials to choose blanking device.

Technical Feature

  • Other
  • New
  • Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles, potato chips packaging machine, for packing different granule
  • Bags, Barrel, Belt, Bottles, Cans, Capsule, Cartons, Case, Film, Foil, Pouch, Stand-up Po
Send Project Inquiry Add Inquiry List

0 Add Favorite

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Type
Other
Condition
New
Application
Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles, potato chips packaging machine, for packing different granule
Packaging Type
Bags, Barrel, Belt, Bottles, Cans, Capsule, Cartons, Case, Film, Foil, Pouch, Stand-up Pouch, potato chips packaging machine
Packaging Material
Glass, Metal, Paper, Plastic, Wood, potato chips packaging machine
Automatic Grade
Automatic
Driven Type
Pneumatic
Voltage
220V/380V
Power
0.75kw
Place of Origin
Hubei, China (Mainland)
Brand Name
KEFAI
Model Number
KF02-G
Weight
240kg
Dimension(L*W*H)
1100mm*900mm*1850mm
Certification
CE ISO
After-sales Service Provided
Engineers available to service machinery overseas
Product name
Hot sale 2017 new style Automatic vertical granule Packing Machine
Material
all stainless steel
Filling volume
1-50/100/500-1000g
Filling method
measure cup and scale weighting
Control
Mitsubishi PLC+Touch screen
Spare parts
provide enough for customers
Operation
Demo video and English manual
Guarantee
12 months,,long time technical support and service
Price
factory reasonable cost

DETAIL DESCRIPTION

potato chips packaging machine

Product Description

This machine is applicable for the dosing and packaging of granule,nuts grain rice peanut chips and puffed food, granulated sugar,medicine and tea,ect which are used in food medical and chemical industries According to different materials to choose blanking device.

Machine features:

1. This machine can finish : forming bag--measuring--material filling—sealing—counting—date code printing

all the work automatically;
2. Photoelectric and tracing system or computer system can be provided without your specific requirements.

3. The PLC/CPU controller has the advantages such as setting the length of the bag; the out put alarm and the

speed and quantity with buttons;

4. This machine can be installed to code printer for 1-3 lines characters such as production and expiry date

according to your special request.

5. Measure cup and scale weighting, high accuracy with no leaking.

Applicable packing film:

Paper/PE, PT/PE, PET/AL/PE, BOPP/PE, Tea filter paper and other compound materials can be heat sealed.

advantage

1.Packing machine is Full Automatic. Feeding, Dosing, Printing (Date), Filling. Bag Forming, and Sealing.

2.Packing machine can made of Carbon steel with powder coating, or Stainless Steel 304.

3:Easy operation. Most of parameter resetting by Touch Screen. Multi-language for client choose.

4:Film moving by Servo motor and a pair of belt, Horizontal and Vertical sealing temperature is independent. Make sure bag is beautiful

and sealing very well.

5: Packing machine have alarming function, any wrong with it will show you soon.

Technical parameters:

Model

KF02-G Q240

KF02-G 300

KF02-G 350

KF02-G 500C

Filling range

1-90ml

10-110ml

50-300ml

100-1000ml

Sealing way

4 side sealing, 3side sealing, back sealing bag



Bag length

30-150mm

30-160mm

40-280mm

60-300mm

Bag width

20-110mm

20-140mm

20-140mm

40-200mm

Packing speed

30-50 bags/min

30-50 bags/min

20-43 bags/min

10-30 bags/min

Applicable film

PET/AL/PE PET/PE NY/AL/PE NY/PE

Max width of film roll

max240mm

max320mmmax350mmmax500mm

Power supply

220V/380V, 50/60HZ, 1.8Kw

Dimension

800*760*1700mm

800*760*1700mm

950*840*1900mm

780*920*2100mm

Weight

250kg

320kg

180kg

450kg

what can be packing

Optional device:

1 Hopper conveyor(automatic materials feeding machine)

2 Date printing machine

3 Batch cutting device

4 Straight cutter and tear mouth(V,U,-)

5 Round hole

6 Euro hole

7 Pinhole

8Gas flushing device

Packaging & Shipping

1)Dedust & Cleaning
2) Lubricate Drive Parts
3) Divide Machine Into Modules
4) Wrap Modules With Plastic Film
5) Packing Modules into Plywood Cases
6)Mark Shipping Mark In The Cases
If any special requirements, we will pack it as requested.



Our Services

Customize Guide

- Propose before buying automatic packing machine:

1) What’s packaging material?

(In order to select the appropriate metering device)

2) What’s the per bag packaging capacity?

(In order to select the appropriate metering device)

3) What’s the capacity for the machine (per minute)?

(In order to select the appropriate transmission device)

4) Packaging film width or packing bag size?

(In order to select the appropriate former)

5) Sealing form?

(In order to choose the suitable sealing device)

6) Whether you need additional device or if there are special requirements?

(In order to calculate the right price)

7) If there are special requirements for the power?

(The default configuration: 200V 50Hz / 380V 50Hz)

For warranty parts and service:
**One year warranty.
**Within warranty period, all exchanges due to defects are free and give matainece service for life long (Buyer is responsible for shipping

charges).
**beyond warranty period ,all the service are not available .

Company Information

Wuhan Kefai Innovation Machinery Co., Ltd. is a professional manufacturer of filling&packing machine with well-equipped

testing facilities and strong technical force for nearly ten years in China ! We are committed to solve all kinds of bottle filling, bagging packing solution.

  • With a good quality, reasonable prices and stylish designs, our products are extensively used in packaging industry and other industries.
  • Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs.
  • We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!

...
