potato chips packaging machine
This machine is applicable for the dosing and packaging of granule,nuts grain rice peanut chips and puffed food, granulated sugar,medicine and tea,ect which are used in food medical and chemical industries According to different materials to choose blanking device.
Machine features:
1. This machine can finish : forming bag--measuring--material filling—sealing—counting—date code printing
all the work automatically;
2. Photoelectric and tracing system or computer system can be provided without your specific requirements.
3. The PLC/CPU controller has the advantages such as setting the length of the bag; the out put alarm and the
speed and quantity with buttons;
4. This machine can be installed to code printer for 1-3 lines characters such as production and expiry date
according to your special request.
5. Measure cup and scale weighting, high accuracy with no leaking.
Applicable packing film:
Paper/PE, PT/PE, PET/AL/PE, BOPP/PE, Tea filter paper and other compound materials can be heat sealed.
advantage
1.Packing machine is Full Automatic. Feeding, Dosing, Printing (Date), Filling. Bag Forming, and Sealing.
2.Packing machine can made of Carbon steel with powder coating, or Stainless Steel 304.
3:Easy operation. Most of parameter resetting by Touch Screen. Multi-language for client choose.
4:Film moving by Servo motor and a pair of belt, Horizontal and Vertical sealing temperature is independent. Make sure bag is beautiful
and sealing very well.
5: Packing machine have alarming function, any wrong with it will show you soon.
Model | KF02-G Q240 | KF02-G 300 | KF02-G 350 | KF02-G 500C |
Filling range | 1-90ml | 10-110ml | 50-300ml | 100-1000ml |
Sealing way | 4 side sealing, 3side sealing, back sealing bag
| |||
Bag length | 30-150mm | 30-160mm | 40-280mm | 60-300mm |
Bag width | 20-110mm | 20-140mm | 20-140mm | 40-200mm |
Packing speed | 30-50 bags/min | 30-50 bags/min | 20-43 bags/min | 10-30 bags/min |
Applicable film | PET/AL/PE PET/PE NY/AL/PE NY/PE | |||
Max width of film roll | max240mm | max320mm | max350mm | max500mm |
Power supply | 220V/380V, 50/60HZ, 1.8Kw | |||
Dimension | 800*760*1700mm | 800*760*1700mm | 950*840*1900mm | 780*920*2100mm |
Weight | 250kg | 320kg | 180kg | 450kg |
what can be packing
Optional device:
1 Hopper conveyor(automatic materials feeding machine)
2 Date printing machine
3 Batch cutting device
4 Straight cutter and tear mouth(V,U,-)
5 Round hole
6 Euro hole
7 Pinhole
8Gas flushing device
1)Dedust & Cleaning
2) Lubricate Drive Parts
3) Divide Machine Into Modules
4) Wrap Modules With Plastic Film
5) Packing Modules into Plywood Cases
6)Mark Shipping Mark In The Cases
If any special requirements, we will pack it as requested.
Customize Guide
- Propose before buying automatic packing machine:
1) What’s packaging material?
(In order to select the appropriate metering device)
2) What’s the per bag packaging capacity?
(In order to select the appropriate metering device)
3) What’s the capacity for the machine (per minute)?
(In order to select the appropriate transmission device)
4) Packaging film width or packing bag size?
(In order to select the appropriate former)
5) Sealing form?
(In order to choose the suitable sealing device)
6) Whether you need additional device or if there are special requirements?
(In order to calculate the right price)
7) If there are special requirements for the power?
(The default configuration: 200V 50Hz / 380V 50Hz)
For warranty parts and service:
**One year warranty.
**Within warranty period, all exchanges due to defects are free and give matainece service for life long (Buyer is responsible for shipping
charges).
**beyond warranty period ,all the service are not available .
Wuhan Kefai Innovation Machinery Co., Ltd. is a professional manufacturer of filling&packing machine with well-equipped
testing facilities and strong technical force for nearly ten years in China ! We are committed to solve all kinds of bottle filling, bagging packing solution.
- With a good quality, reasonable prices and stylish designs, our products are extensively used in packaging industry and other industries.
- Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs.
- We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
...
