GD series belt vacuum drum filter

GD-type folding belt vacuum drum filter is a high-quality, cost-effective solid-liquid separation equipment developed by our company to absorb and absorb foreign advanced technology, develop and innovate. It is a filtration equipment that continuously suc

Technical Feature

  • Customized design, different needs of customers
  • Extraordinary production capacity, low moisture content of filter cake, easy to discharge
  • Simple process layout, saving materials, saving money, and saving effort
  • Advanced structural features, superior pr
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$15000~50000

PRIMARY PARAMETERS

Brand name
Shengshuo
Application
Medicine, mine, corn protein, wheat starch, wastewater treatment
Process input material
-
Process output material
-
Place of origin
China
Equipment material
SS & CS
Power (kW)
Depends on the requirement
Weight (kg)
Depends on the requirement
Outer dimension (mm)
Depends on the requirement
Warranty
One year
Delivery
30 days
Main spare parts
-

MODEL SPECIFICATIONS

Model GD10 GD15 GD20 GD25 GD30 GD35 GD40 GD45 GD50 GD60 GD70 GD75 GD80
Filter area(m2) 10 15 20 25 30 35 40 45 50 60 70 75 80
Vacuum degree(Mpa) 0.06-0.08 0.06-0.08 0.06-0.08 0.06-0.08 0.06-0.08 0.06-0.08 0.06-0.08 0.06-0.08 0.06-0.08 0.06-0.08 0.06-0.08 0.06-0.08 0.06-0.08
Feeding concentration(g/L) 60-100/100-130 60-100/100-130 60-100/100-130 60-100/100-130 60-100/100-130 60-100/100-130 60-100/100-130 60-100/100-130 60-100/100-130 60-100/100-130 60-100/100-130 60-100/100-130 60-100/100-130
Discharging dryness(%) ≥40 ≥40 ≥40 ≥40 ≥40 ≥40 ≥40 ≥40 ≥40 ≥40 ≥40 ≥40 ≥40
Daily capacity(t/d) 3-5 4-6 5.5-8 6.5-10 8-12 9.5-14 11-16 12-18 13.5-20 16-24 18-28 20-30 22-32
Cloth washing water pressure(bar) 4-5 4-5 4-5 4-5 4-5 4-5 4-5 4-5 4-5 4-5 4-5 4-5 4-5
Drum motor power(kw) 2.2 3 3 3 4 4 4 4 4 5.5 5.5 5.5 5.5
Dimension(mm) 3688*2693*1925 4000*3370*2750 4600*3370*2750 5200*3370*2750 5800*3370*2750 5450*4343*3570 5900*4343*3570 5350*4343*3570 6932*4343*3570 7632*4570*3570 8362*4570*3570 10640*4570*3570 10640*4723*3850
Weight(kg) 4500 5400 6300 7200 8400 9500 10950 12400 13300 14800 16200 17200 18500

DETAIL DESCRIPTION


GD series belt vacuum drum filter


GD-type folding belt vacuum drum filter is a high-quality, cost-effective solid-liquid separation equipment developed by our company to absorb and absorb foreign advanced technology, develop and innovate. It is a filtration equipment that continuously suctions, de-drys and automatically discharges under vacuum. Ingenious design, including the perfect performance of innovative technology, makes this product especially suitable for concentrated filtration and de-drying of materials with low solid concentration, finer particle size and higher viscosity. According to different materials, GD type folding belt filter is divided into GD, GDY, WGD and other structural forms.


Features

Customized design, different needs of customers
Extraordinary production capacity, low moisture content of filter cake, easy to discharge
Simple process layout, saving materials, saving money, and saving effort
Advanced structural features, superior product quality
High clarity filtrate with high recovery
Excellent production environment, easy to operate and convenient


GD折带式过滤机
