High Accuracy Flange Electromagnetic Flow Meter(A+E 81F)
Highlights
--aluminum alloy housing electromagnetic flowmeter, good enclosure.
--unique 6 layer circuit board design, immune to electromagnetic interference.
--fault detective supported like excitation circuit turn-off.
--plug & play terminal block
--damp-proof sealed sensor treatment
--reliable blank pipe inspection
Features
--large choice of liner materials like F4, PTFE, F46, Fs and rubber.
--electric conductivity of medium can be used for detection of product change.
--no additional pressure loss.
--no moveable parts and long working life.
--site digital LCD displays instantaneous flow, accumulative flow, flow rate.
--various output method, like 4-20mA, 0-5V, RS485 and pulse.
--compact, split and plug-in types optional.
--change the grounding as the third electrode.
Specifications
| Principle | electromagnetic flowmeter |
| Applicable pipe size | DN 15-800 (1/2'' to 31-1/2'') |
| Applicable media | liquid with conductivity > 5 uS / cm |
| Velocity range | 0.2~8 m/s (0.66 to 26.2 ft/s) |
| Accuracy | 0.5%FS, 1.0%FS |
| Process connection | flange, ANSI / GB / JIS, 1.0MPa, 1.6MPa, 4.0MPa, 16MPa optional |
| Processing temperature | -20 to 150°C, according to lining material |
| Ambient condition | -40 to 80°C, relative humidity <95% |
| Power supply | AC220V, 50Hz / DC24V / battery |
| Display | backlight LCD |
| Operation | 4 light touch buttons |
| Signal output | 4-20mA, loading resistance 750Ω, |
| pulse, 0-3kHz, 5V, | |
| RS485 | |
| Consumption | <8W |
| Cable inlet/outlet | M20*1.5 |
| Protection | transducer IP68, converter IP65 |
| Tube material | carbon steel, stainless steel optional |
| Lining material | PTFE, rubber, polyurethane, F46, Fs optional |
| Electrode material | stainless steel, Hastelloy B, Hastelloy C, Titanium, Tantalum, Platinum optional |
| Grounding | made into a third electrode, same material with electrode |
| Industries | chemical, environmental, metallurgical, pharmaceutical, papermaking, water supply and drainage, etc. |
Company Information
AEAD Technology moves to Chinese first free trade zone --Shanghai Pilot Free Trade Zone in Nov. 2014. That is a milestone for the company development to global market.
AEAD Technology is committed to provide the very best support possible. Our customers have unique service needs, and we offer a variety of service options to support them. For any questions, you will either get the answer or have one of our professionals to contact you within 24 hours.
How to contact us?
If you are interested in electromagnetic flowmeter, please call our office at +86-(0)21-5869 6328.
Alternatively, you can send us an email or use the contact form which can be found on the contact page of our website.
China
