Feature and Description
1. Superior enclosed counter-balanced drive system for smooth silent operations.
2. All steel construction for durability, easy cleaning and pollution control. Precise and efficient separations.
3. Easy sieve replacement
4. Adjustable dividers to obtain quality of grade desired
5. Counter balanced eccentric drive
6. It facilitates the separation of any granular material into lights and heavies.
7. With cyclone duster, Environmentally friendly
8.Main motor is frequency controlled,speed adjustment.
Usage and Application
This machine is used for separating products that are of the same size but with a difference in specific weight. High gravity material will sink while low gravity material will rise. After material enters the drop area, the machine will discharge different material from different exits, achieving accuracy.
The machine is ideal for sifting grain seeds, paddy seeds and wheat seeds. It can be used effectively to remove partially eaten, immature or broken seeds, sand and stones with a diameter below 2mm to ensure maximum quality of the final product. After sifting ,the produce quality ,including weight per thousand seed, bud rate, cleanliness and consistency, will be greatly improved. The machine is practical ,flexible, efficient, environmentally friendly and mobile. It is reliable, stable, the shock absorbing cover is robust. This machine is technically excellent in its class in China.
Technical data
Model | 5XJS |
Capacity (for your sesame) | 3000 Kg/h |
Size (L×W×H) | 3000*1800*2500mm |
Weight | 560 Kg |
Power supply | 380V/50Hz/3-Phase |
Total power | 4 kW |
Air volume of fan machine | 2664-5268 M3/H |
Air pressure of fan machine | 1578-989 Pa |
Sieve size(L×W) | 2000×300 mm |
The diameter of aspirator pipe | 250 mm |
Selection Rate | ≥98% |
Remove light impurity rate | ≥83% |
Remove Heavy impurity rate | ≥80% |
Remove dust way | Cyclone duster |
Package & Shipping
Package : Wooden case package
Shipping :5days
