| SPECIFICATION OF ZS350 | ||||
| Specification | Unit | A | B | C |
| Injection Volume | cm³ | 961 | 1235 | 1502 |
| Injection Weight | g | 884 | 1136 | 1382 |
| Screw Diameter | mm | 60 | 68 | 75 |
| Injection Pressure | M pa | 217 | 170 | 139 |
| Injection Speed | cm³/s | 263 | 338 | 411 |
| Max. Plasticization Capacity | Kg/h r | 178 | 249 | 314 |
| Screw L/D Ratio | L/D | 24:1 | 21:1 | 19;1 |
| Max. Screw Speed | rpm | 205 | ||
| Clamping Force | K n | 3500 | ||
| Clamping Stroke | mm | 640 | ||
| Space Between Tie Bar | mm x mm | 710x 660 | ||
| Max. Daylight | mm | 1360 | ||
| Mold Height(Min-Max) | mm | 250-720 | ||
| Ejector Stroke | mm | 180 | ||
| Ejector Force | K n | 77 | ||
| Hydraulic System Pressure | M pa | 17.5 | ||
| Oil Pump Motor Power | kw | 36 | ||
| Heater Power | kw | 18.5 | ||
| No. of Heater Control Zone | zone | 5 | ||
| Oil Tank Capacity | L | 450 | ||
| Machine Dimension(L*W*H) | m x m x m | 7.3x 1.8x 2.2 | ||
| Machine Weight | kg | 14000 |
Note:
1. Customers offer the place for the sets of machine ,factory offer the design for the sets of machine.
2. payment:
T/T30%, ,70%.
30% as down payment to seller's account by T/T ,70% balanced after inspection and before shipping
3. shipping date:
30 .
Within 30days after receiving the down payment
4. :
Installation and after-sale service:
The machine installation and debugging time should be within 5 days , before seller coming ,the buyer should keep everything ready. the warranty is 1 year ,within this term ,seller offer the easy-wearing parts to buyer for free ,and beyond this term ,seller offer a lowest price for the broken parts. For the installation and debugging workers from seller, the buyer should bear the cost for travelling, board and lodging ,and should pay 100USD/day for one worker .The training site is fixxed by two parties
