Low Cost Factory Steel Structure Workshop Steel Building

high quality corrugate workshop prefab steel building  common norms are as follows: "Steel Design Code" (GB50017-2003)"Cold-formed steel structure technical specifications" (GB50018-2002)"Construction Quality Acceptance of Steel" (GB50205-2001)"Tec

Technical Feature

  • Qingdao, China
  • 2000t/Month
  • L/C, T/T, D/P
  • Steel Structure
  • Warehouse, Workshop
  • ISO, CE
Send Project Inquiry Add Inquiry List

0 Add Favorite

DESIGN SERVICE OVERVIEW

Project Design Scope

Project Service Scope

PRIMARY PARAMETERS

Model NO.
XGZ-SS-00085
Roof & Wall Color
White/Blue/Red/Green
Steel Grade
Q345 or Q235
Life Time
Within 50 Years
Trademark
XGZ
Transport Package
as Per Customeru2032s Requirements
Specification
ISO/SGS/BV
Origin
Qingdao, China
HS Code
9406000090

DETAIL DESCRIPTION

Low Cost Factory Steel Structure Workshop Steel Buildinghigh quality corrugate workshop prefab steel building  common norms are as follows:


"Steel Design Code" (GB50017-2003)
"Cold-formed steel structure technical specifications" (GB50018-2002)
"Construction Quality Acceptance of Steel" (GB50205-2001)
"Technical Specification for welded steel structure" (JGJ81-2002, J218-2002)
"Technical Specification for Steel Structures of Tall Buildings" (JGJ99-9)


high quality corrugate workshop prefab steel building  specifications:

 Low Cost Factory Steel Structure Workshop Steel Building


Main Steel: H section steel column ,  H section steel beam , C/Z purlin

Conection Method: Welding or bolt

Wall&Roof: EPS,Rockwool, glass fiber sandwichpanel, Corrugated steel sheet

Door: Rolled up door or Sliding door(sandwich panel)

Window: Plastic steel or Aluminum alloy window

Surface: Hot dip galvanized or painted.(all colours we can do)

Crane: 5T,10T,15T, 30T ect.

Low Cost Factory Steel Structure Workshop Steel Building


Steel Structure Workshop/Light steel structure warehouse

1. Roof: Color-coated Corrugated Steel Sheet with skylight panel
2. Wall: Color-coated Corrugated Steel Sheet
3. Main Steel Framework: Steel Column, Beam, Purlin and other supporting parts with shot blasting and painting process.
4. Material: Q345
5. Window: Plastic Steel Window
6. Door: Sliding Door plus Canopy (all are made by sandwich panel)
7. PVC Downpipe

Our steel structure building is flexible layout, low foundation cost and can be designed as buyer's requirement.
 Roof Color-coated Corrugated Steel Sheet with skylight panel
 Wall Color-coated Corrugated Steel Sheet
 Window Plastic Steel Window

Low Cost Factory Steel Structure Workshop Steel Building


..
NO.Type
steel structure
1
Material

Main steel strucrure--Q345/Q235 Secondary steel structure--Q235
2
Roof and Wall

Option: Steel sheet,EPS, glass wool, rock wool or PU sandwich panel
3
Door and Window

PVC or Aluminum alloy; sliding door or rolled door
4
Column and Beam

Option: Welded H section
5
Purlin

Option: C type or Z type
6Local Climate
1. Wind speed
7
2. Snow load
8
3. Rain quantity
9
4. Earthquake grade if have
10
More details is preferred.
11
Crane Parameter

If need crane beam, crane tons parameter and lift height are needed
12
Drawing

1. according to clients' drawing
13
2. design as per clients' dimension and requests
14
Package

Naked loaded in shipping container or as per requests.
15
Loading

20 GP, 40HP, 40 GP, 40 OT
16


If you are in need, and we would like to do the design for you, please contact me with these detials.

1. Dimension: Length, width, height, eave height, roof pitch, etc.
2. Doors and windows: Dimension, quantity, position to put them.
3. Local climate: Wind speed, snow load, earthquake resistance etc.
4. Insulation material: Sandwich panel or steel sheet.
5. Crane beam: Do you need crane beam inside the steel structure? And its capacity.
6. If you have other requirements, such as fire proofing, isolated roof, etc, please also inform us.
7. It's better if you have your own drawings or pictures. Please send them to us.
Low Cost Factory Steel Structure Workshop Steel Building

FAQ:
1. What is steel prefabricated house mean and made of?
RE: Steel prefabricated houses are made of high grade painted steel frame/structure as strong skeleton and lined with sandwich panel as wall and roof, these are pre-designed and manufatured in the factory and later assembled on site.
2. Is it safe and can suit to any kind of stringent weather conditions?
RE: Our houses could resistant earthquake, wind, snow, etc.

3. Can you supply design service?
RE: Yes.also supply design service.

4. What is the payment terms?
RE: a) T/T, 30% deposit and other payment will be payed when you receive the ocean bill.
b) 100% L/C at sight

5. How long is delivery?
RE: Generally, the delivery time of sandwich panel is within 7 days; and 30 days for prefabricated house. The exact delivery time should depend on the quantity and confirm with factories.
