Product Info:
A FRAME PULLET CAGE SYSTEM
It is designed for pullets which bird age(rearing period) is from day to day 120 old.this system also can be equipped with automatic feeding,drinking,manure removal and climate control system.it is more popular using in tropic country because it is just working well in open house without climate control system.if it used in close of temperate area,the ventilation and heating system are vital to the pullets.
CAGE SYSTEM
1. each unit dimension of the pullet cage is 1950*500*(350--400)mm,3 cells per unit,with 9-10 birds per cell,each cell dimension is 650*500*(350-400)mm,so each birds can get 390--433 sq.cm. at least within 17 weeks;
2. bottom net is densely welded together,the plastic cushion which put on the bottom cage
mesh can protect the pullet feet and make them more comfortable;
3. both the pullet cage meshes and cage support leg frames are processed by hot dipped galvanization because this system usually working 3 recycles per year and most of them working in high temperature and humidity houses;
4. raising density per unit area can increase 50% - 100% compared with flooring system and the possibilities of infection diseases caused by manure decrease,therefore,death rate is minimized because invariable birds in each cell of cages,and then it is also convenient for observing growth condition of birds,grouping and selection;
5. amount of exercise is small,therefore,more feed is saved by the professional pullet feed trough the adjust board which can be improve inside height with the pullet growing;
6. comparing with the floor raising system,the padding cost for flooring system is deducted,
dramatically reduces birds disability;
DRINKING SYSTEMS
1. it is made up by the square pipes(thickness 2.5mm) or round pipes(thickness 2.0mm) with 360 degree flowing nipple drinkers,water drip cups and water pressure regulators,
terminals,splits,water filters makes sure the water is clean;
2. the drinking system can be automatic nipple drinking line and manual feeders and drinkers for first two weeks while the pullets are too small to get water nipple drinkers;
3. the pipes can be adjusted in higher level as pullets growing bigger day by day because the grid meshes has empty design in the middle place to adjust the pipes going up to higher level;
AUTOMATIC FEEDING SYSTEM
1. both of the traveling hopper(feeding carts) type and chain feeding system are available.
the augers and chain materials made in South Africa,also the best quality worldwide.
2. the feeding cart connected with the silo by the transverse feeding auger is more popular here.In this system, feed is distributed automatically to the feed carts from the feed silos by the spiral augers located in a pipe with 90-150 mm diameter.
MANURE REMOVAL SYSTEM
1. the 1--3 tier of cages can be fitted with manure curtain on the back of the cage meshes in
case of the dropping manure from upper tiers.
2. manure belt system or manure scraper in the manure pits to collect the chicken manure outside of house;the A frame pullet cage system also can be equipped with the manure belts system under the cages which can work together with the manure conveyors.
A Frame Pullet Cage System Advantages
1. Galvanized low carbon steel cold drawn steel wire has high tensile strength and extension rate.
2. Raising density per unit area can increase 50%-100% compared with flooring system;
3. The possibilities of infection diseases caused by manure decrease, thus death rate is minimized;
4. Amount of exercise is small ,thus more feed is saved by the special design of the feed trough which has feed trough adjust board;
5. Convenient for observing growth condition of birds, grouping and selection;
6. Uniformity and health condition are both excellent as there is enough place for birds feeding and drinking;
7. Padding cost for flooring system is deducted;
8. Dramatically reduces birds disability;
9. Less work labor and easy management because all system can be equipped by automatic equipment for feeding, drinking, manure collection and chicken house environment.
The Standard Dimension of A Frame Pullet Cage
| Model NO.: PT-APU1 | Condition: New |
| Color: Silvery White | Type: Breeding, Cleaning, Feeding |
| Tiers: 3 Tiers | Material: Steel |
| Usage: Chicken, Bird | Place of Origin: Henan, China (Mainland) |
| Brand Name: Poul Tech | Model Number: PT- APU |
| Steel Wire Material: Q235 Steel Sire and GSM 275 Steel Sheets | Parts: Nipple Drinker, Feeder, Cups |
| Trademark: POUL TECH | Transport Package: Standard Shipping Packing |
| Specification: CE, PC, ISO | Origin: Henan Province, China |
| HS Code: 8436290000 |
A FRAME PULLET CAGE SYSTEM
It is designed for pullets which bird age(rearing period) is from day to day 120 old.this system also can be equipped with automatic feeding,drinking,manure removal and climate control system.it is more popular using in tropic country because it is just working well in open house without climate control system.if it used in close of temperate area,the ventilation and heating system are vital to the pullets.
CAGE SYSTEM
1. each unit dimension of the pullet cage is 1950*500*(350--400)mm,3 cells per unit,with 9-10 birds per cell,each cell dimension is 650*500*(350-400)mm,so each birds can get 390--433 sq.cm. at least within 17 weeks;
2. bottom net is densely welded together,the plastic cushion which put on the bottom cage
mesh can protect the pullet feet and make them more comfortable;
3. both the pullet cage meshes and cage support leg frames are processed by hot dipped galvanization because this system usually working 3 recycles per year and most of them working in high temperature and humidity houses;
4. raising density per unit area can increase 50% - 100% compared with flooring system and the possibilities of infection diseases caused by manure decrease,therefore,death rate is minimized because invariable birds in each cell of cages,and then it is also convenient for observing growth condition of birds,grouping and selection;
5. amount of exercise is small,therefore,more feed is saved by the professional pullet feed trough the adjust board which can be improve inside height with the pullet growing;
6. comparing with the floor raising system,the padding cost for flooring system is deducted,
dramatically reduces birds disability;
DRINKING SYSTEMS
1. it is made up by the square pipes(thickness 2.5mm) or round pipes(thickness 2.0mm) with 360 degree flowing nipple drinkers,water drip cups and water pressure regulators,
terminals,splits,water filters makes sure the water is clean;
2. the drinking system can be automatic nipple drinking line and manual feeders and drinkers for first two weeks while the pullets are too small to get water nipple drinkers;
3. the pipes can be adjusted in higher level as pullets growing bigger day by day because the grid meshes has empty design in the middle place to adjust the pipes going up to higher level;
AUTOMATIC FEEDING SYSTEM
1. both of the traveling hopper(feeding carts) type and chain feeding system are available.
the augers and chain materials made in South Africa,also the best quality worldwide.
2. the feeding cart connected with the silo by the transverse feeding auger is more popular here.In this system, feed is distributed automatically to the feed carts from the feed silos by the spiral augers located in a pipe with 90-150 mm diameter.
MANURE REMOVAL SYSTEM
1. the 1--3 tier of cages can be fitted with manure curtain on the back of the cage meshes in
case of the dropping manure from upper tiers.
2. manure belt system or manure scraper in the manure pits to collect the chicken manure outside of house;the A frame pullet cage system also can be equipped with the manure belts system under the cages which can work together with the manure conveyors.
A Frame Pullet Cage System Advantages
1. Galvanized low carbon steel cold drawn steel wire has high tensile strength and extension rate.
2. Raising density per unit area can increase 50%-100% compared with flooring system;
3. The possibilities of infection diseases caused by manure decrease, thus death rate is minimized;
4. Amount of exercise is small ,thus more feed is saved by the special design of the feed trough which has feed trough adjust board;
5. Convenient for observing growth condition of birds, grouping and selection;
6. Uniformity and health condition are both excellent as there is enough place for birds feeding and drinking;
7. Padding cost for flooring system is deducted;
8. Dramatically reduces birds disability;
9. Less work labor and easy management because all system can be equipped by automatic equipment for feeding, drinking, manure collection and chicken house environment.
The Standard Dimension of A Frame Pullet Cage
| Item No. | Cell Length | Cell Depth | Cell Height | Unit Dimension | Cells/Unit/Set | Tiers/ Set | Birds/cell/ unit/set | Rearing period (weeks) |
| PT-APU3 | 650 | 600 | 350 | 1950*600*350 | 3/6 | 3 | 10/18/180 | 1-10/16 |
| PT-APU4 | 650 | 600 | 350 | 1950*600*350 | 3/8 | 4 | 10/24/240 | 1-10/16 |
