Automatic Granule Packaging Machine
(DXD-720C)
It is assembled by main vertical packing machine, 10 head weigher, Z type elevator, finished conveyor, platform.
Use:
Suitable for packing materials like all kinds of fried food, potato chips, shimp, sweets, chocolate, biscuits, peanuts, rice, grain, seeds, pistachio, coffee beans, beans, tea, frozen food and medicine etc.
Can finish the feeding, weighing, filling and date coding with high accuracy and efficiency, meantime no damage to materials.
Features:
1. Imported PLC control system, easy-operating, visual touch screen.
2. Servo film feeding system, correct position, both sealing and cutting adopt automatic correction device, achieving high level of automation.
3. Adopt Intelligent temperature controller, ensure nice, smooth sealing.
4. Perfect automatic alarming protective function, reducing the consumption to the lowest level.
5. Combined with automatic weighing equipments can complete the automatic feeding, weighing, bag filling, date printing and automatic counting.
6. Different Type of bag making: Can make pillow bag, punched hanging bag according to customer's request.
Main Technical Parameters:
(DXD-720C)
It is assembled by main vertical packing machine, 10 head weigher, Z type elevator, finished conveyor, platform.
Use:
Suitable for packing materials like all kinds of fried food, potato chips, shimp, sweets, chocolate, biscuits, peanuts, rice, grain, seeds, pistachio, coffee beans, beans, tea, frozen food and medicine etc.
Can finish the feeding, weighing, filling and date coding with high accuracy and efficiency, meantime no damage to materials.
Features:
1. Imported PLC control system, easy-operating, visual touch screen.
2. Servo film feeding system, correct position, both sealing and cutting adopt automatic correction device, achieving high level of automation.
3. Adopt Intelligent temperature controller, ensure nice, smooth sealing.
4. Perfect automatic alarming protective function, reducing the consumption to the lowest level.
5. Combined with automatic weighing equipments can complete the automatic feeding, weighing, bag filling, date printing and automatic counting.
6. Different Type of bag making: Can make pillow bag, punched hanging bag according to customer's request.
Main Technical Parameters:
| Packing speed | 15-60bags/min |
| Bag-making size | (L))150-450mm (W)150-350mm |
| Filling range | 100-5000g |
| Packing material | OPP/CPP PET/PE PET-AL/PE Paper Composite etc. |
| Film width | 180-720mm |
| Film thickness | 0.06-0.10mm |
| Air consumption | 0.6m3/min 0.6MPa |
| Power supply | AC220V/380V 50/60Hz 4.5Kw |
| Machine dimension | (L)2150× (W)1500× (H)1750+2000mm |
| Machine weight | 800kg |
