CE approved puffing rice snack food packing machine line
Brief introduction:
This automatic food weighing and packing machine is consists of vertical automatic packing machine, 10-heads combination weigher, z type elevator(with vibration feeder),supporting plat form and finished products conveyor. It can realize from weighing, filling to packaging automatically.
Application
It is suitable to package fragile materials demanding high accuracy, such as grains, puffed food, crispy, rice, jelly, candy, pistachio, apple slices, dumpling, chocolate, pet food, small hardwares, medicine, etc.
Features:
1. It employs imported PLC computer control system, Chinese and English touch screen operating system, the working condition and operating instructions can be show clearly.
2. It is using high precision servo film transporting system, transport membrane smooth, with automatic photoelectric tracking system, high positioning accuracy.
3. Intelligent digital temperature control system, temperature control stability, match with tooth profile sealing device, ensure perfect sealing.
4. Automatic fault alarm display function, such as low temperature, no packing film, no material and so on.
5. Film drawing down system by servo motor , horizontal sealing controlled by pneumatic control
6. It is a fully automatic equipment can automatically complete all packaging process of measuring, feeding, filling, bag making, date printing, finished product output.
7. It is with the advantage of high accuracy, high efficiency without crushing the materials. And with low cost high gain, high speed and efficiency.
Parameter:
| Model No. | TD-420 | TD-520 | TD-620 | TD-720 |
| packing speed | 5-60bags/min | 5-60bags/min | 5-60bags/min | 5-60bags/min |
| Bag making size | 60-300mm(L) 60-200mm(W) | 80-400mm(L) 150-250mm(W) | 200-400mm(L) 100-330mm(w) | 200-380mm(L) 140-350mm(w) |
| Type of bag | Pillow bag, gusseted bag, punched bag hanging bag | |||
| Max film width | 420mm | 520mm | 620mm | 720mm |
| Film thickness | 0.04-0.09mm | 0.04-0.09mm | 0.04-0.09mm | 0.04-0.09mm |
| Pulling belt type | Single belt | Double belts | Double belts | Double belts |
| Air Consumption | 0.65Mpa 0.3m3/min | 0.65Mpa 0.3m3/min | 0.8Mps 0.5 m3/min | 0.8Mps 0.5 m3/min |
| Supply Voltage | 220v/380v, single/three phases, 50/60Hz. or as per your local voltage | |||
| Dimension | 1530x970x1600mm | 1440x1216x1796mm | 1440x1216x1796mm | 1780x1350x2050mm |
| Weight | 450kg | 600kg | 750kg | 850kg |
1. main packing machine
2. 10 heads combination weigher
3. Z type bucket elevator
4. Vibration feeder
5. Supporting platform
6. Finished product conveyor
Main electrical equipment list:
| Item | Name | Brand | Origin | Remark |
| 1 | Touch-sensitive screen | WEINVIEW | Taiwan of China | color screen |
| 2 | Programmer controll system | Mitsubishi/sinmmens | Japan | |
| 3 | Servo motor | Schneider | Germany | |
| 4 | Cylinder | Airtac | Taiwan of China | |
| 5 | Electromagnetic valve | JINGQI | Taiwan of China | |
| 6 | Intermediate relay | Weidmuller | Germany | |
| 7 | Photoelectric eye | BEDELI | Taiwan of China | |
| 8 | Solid state relay | XIANLI /OMRON |
Packaging & Shipping
All parts of our packing machine are packed in the standard wooden case for exporting.
If it is in a full containers, the container will be loaded in our factory by our workers. Also, all the machines will be fixed onto the container by steel wires. So it is safe and strong enough for a long journey from our factory to your place.
Our Services
1. the warranty time is one year from the date you get the machine, except the easy-wear parts.
2. If any parts are found defective in quality in the first year, we shall replace it freely.
3. we are responsible for the smooth operation of the machines. If you have any problem during production, just feel free to contact us. We assure you our soonest response.
Payment
We accept different method for payment, just like TT, LC, escrow. You just need to choose one which is conveninet and safe for you.
Payment terms: 40% deposit, the balance against copy of B/L or 100% L/C at sight.
Delivery: 15-20 days for semi automatic packing machine
30-35 dasy for full set of fully automatic packing line.
Installation
1. We will send our engineers to install the plant and train your workers for the full set of fully automatic packing machine with weigher.
2. The semi automatic packing machine is easier. We will make testing in our factory for all parts. And We will send you the operation manual.
