Stainless Steel Mixing Tank
This mixing pot apply to mix, homogenization, dispersion, heating, cooling, circulation,
Pump materials and other functions.
1. Apply to cosmetics, food, chemical and pharmaceutical
This mixing pot apply to mix, homogenization, dispersion, heating, cooling, circulation, pump materials and other functions are all one,
It is the ideal equipment for produce lotion, cream, cosmetics, etc.
2. Performance and characteristics
(1) With high speed dispersion device and strong mixing viscous dispersion of solid and liquid materials; The main stirring with variable speed device,
It can reduce the formation of bubbles when high viscosity under low temperature, the gear pump can cyclic discharge,
So it can speed up the product formation and discharging.
Feature:
• Volume:100L~5000L and multiple specification, also can design and manufacture according to customers' requirement.
• Jacket can pass steam (or hot water), can also pass the cooling water. There are full type jacket,half-pipe coil jacket, dimple jacket and plate coil jacket. Jacket outside is covered with insulation, thermal insulation material for rock wool (warm) or PU (cold).
• The connection adopts Tri-clamp, and the tanks' inner layer use 304 or 316L. The inner surface mirror polishing Ra≤0.28μm~0.6μm. Outer surface can be polished, wire drawn and sand blasted according to customers' requirement.
Structure Characteristics
Main Technical Parameters
This mixing pot apply to mix, homogenization, dispersion, heating, cooling, circulation,
Pump materials and other functions.
1. Apply to cosmetics, food, chemical and pharmaceutical
This mixing pot apply to mix, homogenization, dispersion, heating, cooling, circulation, pump materials and other functions are all one,
It is the ideal equipment for produce lotion, cream, cosmetics, etc.
2. Performance and characteristics
(1) With high speed dispersion device and strong mixing viscous dispersion of solid and liquid materials; The main stirring with variable speed device,
It can reduce the formation of bubbles when high viscosity under low temperature, the gear pump can cyclic discharge,
So it can speed up the product formation and discharging.
Feature:
• Volume:100L~5000L and multiple specification, also can design and manufacture according to customers' requirement.
• Jacket can pass steam (or hot water), can also pass the cooling water. There are full type jacket,half-pipe coil jacket, dimple jacket and plate coil jacket. Jacket outside is covered with insulation, thermal insulation material for rock wool (warm) or PU (cold).
• The connection adopts Tri-clamp, and the tanks' inner layer use 304 or 316L. The inner surface mirror polishing Ra≤0.28μm~0.6μm. Outer surface can be polished, wire drawn and sand blasted according to customers' requirement.
Structure Characteristics
| Material: | SS304 or SS316L or Duplex stainless or 904L |
| Design Pressure: | -1 -10 Bar (g) or ATM B9 |
| Work Temperature: | 0-200 °C |
| Volumes: | 100L~30000L |
| Construction : | Vertical type or Horizontal type |
| Jacket type : | Dimple jacket, full jacket, or coil jacket |
| Structure : | Single layer vessel, vessel with jacket, vessel with jacket and insulation |
| Heating or cooling function | According to the heating or cooling requirement , the tank will have jacket for required function |
| Oppilation Motor: | ABB, Siemens, SEW or Chinese brand |
| Surface Finish: | Mirror Polish or Matt polish or Acid wash&pickling or 2B |
| Standard components | Manhole, CIP cleaning ball,sight glass |
| Optional components : | Vent filter, Temp. Gauge, display on the gauge directly on the vesselTemp sensor PT100,digital display on the control cabinet by instrument Temp sensor with control for heating and cooling Level gauge with digital display on the control cabinet by instrument Load cell Valves |
| Applications: | Wine, Beer Juices Food & Beverage Pharmaceutical Biotechnology & Laboratory Medical &Medical Device Chemical Industry Painting Industrial |
| Parameter | ZT 300 | ZT400 | ZT500 | ZT600 | ZT1000 | ZT2000 | ZT3000 | ZT5000 | ZT10000 | |
| Cubage(L) | 300 | 400 | 500 | 600 | 1000 | 2000 | 3000 | 5000 | 10000 | |
| Pressure | Internal bladder | ≤ 0.2Mpa | ||||||||
| Insert set | ≤ 0.3Mpa | |||||||||
| Power (Kw) | 0.55 | 0.55 | 0.75 | 0.75 | 1.1 | 1.5 | 1.5 | 2.2 | 3 | |
| Speed of impeller | 18=200r/min | |||||||||
| Outlook size (mm) | Diameter | 900 | 1000 | 1150 | 1150 | 1400 | 1580 | 1800 | 2050 | 2500 |
| Height | 2200 | 2220 | 2400 | 2500 | 2700 | 3300 | 3600 | 4200 | 5000 | |
| Heat transfer area | 2 | 2.4 | 2.7 | 3.1 | 4.5 | 7.5 | 8.6 | 10.4 | 20.2 |
