IDENTIFICATION CODE
4QG1.2-50-0.37
4: Well diamater: 96mm(4")
QG: pump name
D: Single motor( Three phase without D)
1.2: Capacity(m3/h)
50: rated head(m)
0.37: motor power(kW)
APPLICATIONS
For water supply from wells or reservoirs.
For domestic use , for civil and industrial applications.
For garden use and irrigation.
OPERATING CONDITIONS
Maximum fluid temperature up to +35ºC
Maximum sand content: 0.25%
Maximum immersion: 50M(oil-filled motor)
Minimum well diameter: 2"/3"/4"
MOTOR AND PUMP
Rewindable motor, full obturated screen motor
Three phase: 380v-415v/50hz or 60hz
Single phase: 220v-240v/50hz or 60hz
Equip with start control box or digital auto-control box
Pumps are designed by casing stressed
NEMA dimension standard
OPTIONS ON REQUEST
Special mechanical seal
Other voltages or frequency viable
FAQ
Q: What is your MOQ of this item?
A: Our MOQ is a full 20ft container, first time cooperation, we accept trial order to check quality.
Q: Is it acceptable to make customers' own brand?
A: Sure, we can do OEM.
Q: What are your payment terms?
A: 30% T/T deposit, 70% against documents, or L/C at sight.
Q: How long is your warranty?
A: One year!
Q: What is the delivery time?
A: 25-30 days after receiving your L/C or T/T deposit.
Contacting information:
TAIZHOU QIANTAO PUMPS CO.,LTD(CHIMP)
TEL: 0086-576-86313665
FAX: 0086-576-86334238
WEB: www.chimppumps.com
4QG1.2-50-0.37
4: Well diamater: 96mm(4")
QG: pump name
D: Single motor( Three phase without D)
1.2: Capacity(m3/h)
50: rated head(m)
0.37: motor power(kW)
APPLICATIONS
For water supply from wells or reservoirs.
For domestic use , for civil and industrial applications.
For garden use and irrigation.
OPERATING CONDITIONS
Maximum fluid temperature up to +35ºC
Maximum sand content: 0.25%
Maximum immersion: 50M(oil-filled motor)
Minimum well diameter: 2"/3"/4"
MOTOR AND PUMP
Rewindable motor, full obturated screen motor
Three phase: 380v-415v/50hz or 60hz
Single phase: 220v-240v/50hz or 60hz
Equip with start control box or digital auto-control box
Pumps are designed by casing stressed
NEMA dimension standard
OPTIONS ON REQUEST
Special mechanical seal
Other voltages or frequency viable
| MODEL | POWER | MAX.FLOW | MAX.HEAD | OUTLET | Spead | Dimensions(mm) | ||
| 1~220v/240v | 3~380v/415v | kW | HP | (m3/h) | (M) | (inch) | (1/min) | ΦD |
| 2QGD1-48-0.25 | 2QG1-48-0.25 | 0.25 | 0.35 | 1 | 48 | 0.5" | 2850 | 52 |
| 3QGD1.5-72-0.37 | 3QG1.5-72-0.37 | 0.37 | 0.5 | 1.5 | 72 | 1" | 2850 | 74 |
| 3QGD1.5-90-0.55 | 3QG1.5-90-0.55 | 0.55 | 0.75 | 1.5 | 90 | 1" | 2850 | 74 |
| 3QGD2-103-0.75 | 3QG2-103-0.75 | 0.75 | 1 | 2 | 103 | 1" | 2850 | 74 |
| 4QGD1-60-0.37 | 4QG1-60-0.37 | 0.37 | 0.5 | 2 | 105 | 1" | 2850 | 96 |
| 4QGD1.2-50-0.37 | 4QG1.2-50-0.37 | 0.37 | 0.5 | 2 | 100 | 1" | 2850 | 96 |
| 4QGD1.2-60-0.55 | 4QG1.2-60-0.55 | 0.55 | 0.75 | 2 | 125 | 1" | 2850 | 96 |
| 4QGD1.8-50-0.55 | 4QG1.8-5-0.55 | 0.55 | 0.75 | 2.5 | 100 | 1" | 2850 | 96 |
| 4QGD1.8-80-0.75 | 4QG1.8-80-0.75 | 0.75 | 1.0 | 2.5 | 130 | 1" | 2850 | 96 |
| 4QGD1.2-100-0.75 | 4QG1.2-100-0.75 | 0.75 | 1.0 | 2 | 150 | 1" | 2850 | 96 |
FAQ
Q: What is your MOQ of this item?
A: Our MOQ is a full 20ft container, first time cooperation, we accept trial order to check quality.
Q: Is it acceptable to make customers' own brand?
A: Sure, we can do OEM.
Q: What are your payment terms?
A: 30% T/T deposit, 70% against documents, or L/C at sight.
Q: How long is your warranty?
A: One year!
Q: What is the delivery time?
A: 25-30 days after receiving your L/C or T/T deposit.
Contacting information:
TAIZHOU QIANTAO PUMPS CO.,LTD(CHIMP)
TEL: 0086-576-86313665
FAX: 0086-576-86334238
WEB: www.chimppumps.com
China
