Packing&Delivery:
Packing Details: standard wooden case
Delivery Time: 20days after your order
Specifications:
Features:
The rotor pump can be used as a high viscosity materials delivery pump.In conjunction with reasonable driving torque,its unique working principle can ensure that the rotor pump will convey materials continuously without stopping and the performance will not be damaged when the materials are being conveyed. The viscosity of the medium conveyed is up to100000CP and liquid materials with a solid content of 55% can be conveyed.
Advantages:
It adopts externally mounted dynamic and static mechanical seals. It can be subject to direct water washing. Resistant to high pressure, it will not easily wear and has no leakage. The pump impeller is separate from the transmission gear, and concern space is kept between all parts in the pump cavity to ensure that they do not contact each other. It has such advantages as no wear, low noise, good reliability, long service life, energy conservation and consumption reduction.
Packing Details: standard wooden case
Delivery Time: 20days after your order
Specifications:
| Model | Displacement per 100 revolutions | Rotation speed (RPM) | Flow(T/H) | power (kw) | Connection size(mm) |
| OSP-L/R-3 | 3 | 100-200 | 0.5 | 0.55 | 25*1.5 |
| OSP-L/R-6 | 6 | 100-200 | 1 | 0.75 | 25*1.5 |
| OSP-L/R-8 | 8 | 100-200 | 2 | 1.5 | 32*1.5 |
| OSP-L/R-12 | 12 | 100-200 | 3 | 2.2 | 38*1.5 |
| OSP-L/R-20 | 20 | 100-200 | 5 | 3 | 38*1.5 |
| OSP-L/R-30 | 30 | 100-200 | 7 | 4 | 38*1.5 |
| OSP-L/R-36 | 36 | 100-200 | 8 | 4 | 38*1.5 |
| OSP-L/R-52 | 52 | 100-200 | 10 | 5.5 | 50.8*1.5 |
| OSP-L/R-70 | 70 | 100-200 | 15 | 7.5 | 63.5*1.5 |
| OSP-L/R-78 | 78 | 100-200 | 18 | 7.5 | 63.5*1.5 |
| OSP-L/R-100 | 100 | 100-200 | 20 | 11 | 76*2 |
| OSP-L/R-160 | 160 | 100-200 | 35 | 18.5 | 89*2 |
| OSP-L/R-200 | 200 | 100-200 | 40 | 22 | 102*3 |
The rotor pump can be used as a high viscosity materials delivery pump.In conjunction with reasonable driving torque,its unique working principle can ensure that the rotor pump will convey materials continuously without stopping and the performance will not be damaged when the materials are being conveyed. The viscosity of the medium conveyed is up to100000CP and liquid materials with a solid content of 55% can be conveyed.
Advantages:
It adopts externally mounted dynamic and static mechanical seals. It can be subject to direct water washing. Resistant to high pressure, it will not easily wear and has no leakage. The pump impeller is separate from the transmission gear, and concern space is kept between all parts in the pump cavity to ensure that they do not contact each other. It has such advantages as no wear, low noise, good reliability, long service life, energy conservation and consumption reduction.
