3HP dust collector with 24" Cartridge filter
01) Motor: 2, 200W
02) Fan diameter: 305mm
03) Inlet diameter: 150mm
04) Number of intake holes: 3 x 100
05) Air speed-50Hz: 2, 300CFM/65.09cubic meter/min
06) Air speed-60Hz: 2, 760CFM/78.11cubic meter/min
07) Bag diameter: 500mm
08) Bag height: 850mm
09) Bag volume: 0.307cubic meter
10) Cartridge filter:
11) Filter rate: 1 micro
12) Drum diameter: 510mm
13) Drum height: 610mm
14) Net/gross weight: 64/69kg
15) Packing size:
1, 170 x 560 x 570mm (carton 1),
530 x 530 x810mm (carton 2),
530 x 530 x810mm (carton 3)
16) Units per 20-foot container: 30
| 01) | Motor: 2,200W |
| 02) | Fan diameter: 305mm |
| 03) | Inlet diameter: 150mm |
| 04) | Number of intake holes: 3 x 100 |
| 05) | Air speed-50Hz: 2,300CFM/65.09cubic meter/min |
| 06) | Air speed-60Hz: 2,760CFM/78.11cubic meter/min |
| 07) | Bag diameter: 500mm, Bag height: 850mm |
| 08) | Bag volume: 0.307cubic meter |
| 09) | Cartridge filter included |
| 10) | Filter rate: 1 micro |
| 11) | Drum diameter: 510mm |
| 12) | Drum height: 610mm |
| 13) | Net/gross weight: 64/69kg |
| 14) | Packing size:1,170 x 560 x 570mm (carton 1), 530 x 530 x810mm (carton 2), 530 x 530 x810mm (carton 3) |
| 15) | Units per 20-foot container: 32 |
