Industrial Multi Stage Stainless Steel Top Entry Single Bag Filter Housing

Industrial Multi Stage Stainless Steel Top Entry Single Bag Filter HousingSurface FinishFinish TypeMechanical polishing, Electrolytic Polishing, Sand blasting, pickingPolishingpressureMirror Polish Ra≤0.4μm Operating ConditionsMax Operatingpressu

Technical Feature

  • Ningbo, China
  • 1000PCS/ Month
  • L/C, T/T
  • Ss 304/316/316L
  • 1.0MPa
  • Electric Power
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$150~680

PRIMARY PARAMETERS

Model NO.
BF-1S BF-2S BF-4S
Trademark
CHFNA
Transport Package
Wooden
Origin
Wenzhou, Zhejiang

DETAIL DESCRIPTION

Industrial Multi Stage Stainless Steel Top Entry Single Bag Filter Housing


Industrial Multi Stage Stainless Steel Top Entry Single Bag Filter Housing


Surface Finish
Finish TypeMechanical polishing, Electrolytic
Polishing, Sand blasting, picking
Polishing
pressure		Mirror Polish Ra≤0.4μm

 Operating Conditions
Max Operating
pressure.		1.0MPa
Max Operating
Temp.		150ºC

Material
Shell304, 316L
O-ringEPDM, PTFE, Viton, Silicone

Connection
Shell ConnectionFlange
In-outlet Flange,Quick-open, Screw thread
Pressure Gauge
(optional)		M14×1.5 Female Screw thread

Vent Valve(optional)1/4'' Male Screw thread

The above-mentioned data is the standard, it can customize according to customer's requirements.

Company ShIndustrial Multi Stage Stainless Steel Top Entry Single Bag Filter Housingow
