Top Entry 180 Degree RJ45 PCB Jack with LED

SpecificationElectrical1. Current Rating: 1.5 amps2. Voltage Rating: 125vac3. Insulation Resistance: 500Ωmin4. Contact Resistance: 30Ωmax5. Withstanding Voltage: AC 1000V RMS 50Hz or 60Hz 1 minMechanical1. Insertion Force: 2.2KG. F max2. Retention

Technical Feature

  • Ningbo, China
  • 30, 000, 000
  • L/C, T/T, Western Union, Paypal
  • PCB, Communication
  • Optional
  • Rj Connector
Send Standard Inquiry Add Inquiry List

0 Add Favorite

$0~5.98

PRIMARY PARAMETERS

Customized
Customized
Working Frequency
High Frequency
Feature
Fire/Flame Retardant
Cards Support
Single Card
Shield
Phosphor Bronze
Thickness
Option/ Gold Flash
Cage
Optional
Housing
Glass Filled Polyester
Trademark
ZSNOW
Transport Package
Custom Plastic Tray, Box
Specification
ROHS
Origin
Ningbo

DETAIL DESCRIPTION

Specification
Electrical
1. Current Rating: 1.5 amps
2. Voltage Rating: 125vac
3. Insulation Resistance: 500Ωmin
4. Contact Resistance: 30Ωmax
5. Withstanding Voltage: AC 1000V RMS 50Hz or 60Hz 1 min
Mechanical
1. Insertion Force: 2.2KG. F max
2. Retention Strength: 7.7KG. F min between jack and plug
3. Durability: 600 mating cycles min
Material
1. Housing: ABS RESIN(UL94V-0)
PBT(UL94V-0)
PA66(UL94V-0)
PA46(UL94V-0)
2. Contact Wire: Diameter 0.45mm phosphor bronze gold plating over
Nickel 0.35mm thickness phosphor bronze alloy selective gold Plating over nickel
3. Shield: 0.20~0.25mm thickness brass with tin plated
4. Gold Plating: Gold flash, 3u inch, 6u inch, 15u inch, 30u inch, 50u inch
