Characteristics:
Loading factor shall be up to 80%, much higher than that of ordinary mixer
Mixing vessel shall continuously carry out composite motion of horizontal moving, rotating and rolling.
Materials shall be free of segregation, lamination and accumulation resulting from centrifugal force and gravity
All materials in mixing vessel shall be mixed thoroughly
No dead area in mixing vessel
High efficiency of mixing
Arc transmission, mirror polish of interior and exterior of mixing vessel shall prevent materials from retention.
Discharge port deviates from center line of mixing vessel so as to discharge materials thoroughly.
Large feeding port and discharge port are adopted for convenience of material loading, product discharge and vessel cleaning.
Material of Mixing vessel and exterior of rack: S.S.304/S.S.316L
Mixing vessel can be washed with water if necessary.
Application:
Mixing of powder or granulate in pharmacy, chemical, food, light industry, electronics, machinery, mining, metallurgy, national defense industry, scientific research, etc.
Technical data:
| Model | Total volume (L) | Max. working volume(L) | Max. load (KG) | Main shaft speed (rpm) | Motor power (KW) | Outline dimension(mm) | N.W. (KG) | ||
| L | W | H | |||||||
| TD-1 | 1 | 0.8 | 0.5 | 15-30 | 0.12 | 500 | 600 | 600 | 50 |
| TD-5 | 5 | 4 | 2.4 | 15-30 | 0.25 | 600 | 1000 | 1000 | 150 |
| TD-15 | 15 | 12 | 7.5 | 15-30 | 0.37 | 700 | 1000 | 1000 | 200 |
| TD-50 | 50 | 40 | 25 | 0-8 | 1.1 | 1000 | 1400 | 1200 | 200 |
| TD-100 | 100 | 80 | 50 | 0-8 | 1.5 | 1200 | 1700 | 1500 | 500 |
| TD-200 | 200 | 160 | 100 | 0-8 | 2.2 | 1400 | 1800 | 1600 | 800 |
| TD-400 | 400 | 320 | 200 | 0-8 | 4 | 1800 | 2100 | 1950 | 1200 |
| TD-600 | 600 | 480 | 300 | 0-8 | 5.5 | 1900 | 2100 | 2250 | 1500 |
| TD-800 | 800 | 640 | 400 | 0-8 | 7.5 | 2200 | 2400 | 2300 | 2000 |
| TD-1000 | 1000 | 800 | 600 | 0-8 | 7.5 | 2250 | 2600 | 2600 | 2500 |
