Engler Viscometer-Engler Viscometer (Double Units) -Oil Testing Instrument
I.Description
Engler Viscometer is designed and made as per the National Standard GB/T266 "Test Methods for Engler Viscosity of Petroleum Products" and the Industry Standard JTJ052Specification and Test Methods of Bitumen and Bituminous Mixture for Highway Engineering. It is used to determine the ratio obtained by dividing the time of flow, in s, of 200 ml of material using an Engler viscometer at a selected temperature by a factor representing the time of flow, in s, for an equal volume of water at 20 ºC. The ratio is the Engler viscosity of the sample. The instrument can make determination for 2 samples at the same time in the same temperature environment. It can also calculate the average value of these test results. It is the best instrument for Engler viscosity of petroleum products and bituminous materials determination.
II. Main technical specification and parameters
1. Power supply: AC 220 V±10%, 50 Hz;
2. Standard water value: 51±1 s;
3. Temperature measurement range: 0ºC~100 ºC;
4. Temperature controlling accuracy: ±0.1 ºC;
5. Engler viscometer thermometer: as per standard GB/T514;
6. Measuring flask specification: 100±0.2 ml (asphalt sample is 50±0.2 ml);
7. Inner container: stainless steel;
8. Time measurement range: the maximum is 999 s;
9. Timing mode: LED timer;
10. Heating power: 700 W;
11. Ambient temperature: -10ºC~+40 ºC;
12. Relative humidity: ≤85%;
13. Total power consumption: not more than 800 W;
Measurement record
| Standard water temperature | 25±0.2 ºC | Measured water value at first time | |
| Standard water value | 11.4±0.2 s | Measured water value at second time | |
| Real temperature | ºC | Average water value |
Full set and technical documents
1. Full set
| No | Name | Unit | Quantity |
| 1 | Main unit | Set | 1 |
| 2 | Temperature sensor | Piece | 1 |
| 3 | Receiving flask (100 ml) | Piece | 2 |
| 4 | Engler thermometer 0~50 ºC, scale division is 0.1 ºC | Piece | 1 |
| 5 | Engler thermometer 0~100 ºC, scale division is 1.0 ºC | Piece | 1 |
| 6 | Wooden stopper of viscometer | Piece | 2 |
| 7 | Fuse 10 A (Φ5×20) | Piece | 2 |
| 8 | Stopping ring for thermometer (1#) | Piece | 2 |
Packing:
