Feature
Measuring Range cp or mPa. S: 4_40000000(mPa. S)
Speed Range (RPM): 0.1~100RPM
Number of Spindles: 4 kinds (The 0th rotor for select and match)
Accuracy: ± 2.0%
Repeatability: 0.5%
Voltage: 220V± 10V
SNB-2 Digital LCD Viscometer, applies stepping motor based on 16-bytes microcomputer processor, with blue screen TFL-LCD. With even rotate speed, distinctive keystrokes, programming, and alarming system. RTD ensures real-time temperature measurement and control during viscosity measurement, with an accuracy of 0.1degree. Temperature range of measurement is between -20degree and 120degree. Displayer tells directly viscosity, rotary speed, temperature, centesimal torsion, serial number of the spindle and maxim viscosity that can be measured at present rotary speed of the spindle used. RS232 interface printing, the interval of which can be set by users themselves. Master control board and (). The circuit is designed by the most advanced microcomputer processor in the world, thus the structure is reasonable and compact. The full scale and levels of lineal measure are measured and adjusted through a PC interface, whose measuring capability is up to the advanced standards of similar types abroad.
Accessories Available: ULA, Small Sample Adapter, Standard Oil, Printer, Viscometer Dedicated Constant Temperature Flume, Remote Controller, Thermosel, SNB data collection and graphing software.
Measuring Range cp or mPa. S: 4_40000000(mPa. S)
Speed Range (RPM): 0.1~100RPM
Number of Spindles: 4 kinds (The 0th rotor for select and match)
Accuracy: ± 2.0%
Repeatability: 0.5%
Voltage: 220V± 10V
SNB-2 Digital LCD Viscometer, applies stepping motor based on 16-bytes microcomputer processor, with blue screen TFL-LCD. With even rotate speed, distinctive keystrokes, programming, and alarming system. RTD ensures real-time temperature measurement and control during viscosity measurement, with an accuracy of 0.1degree. Temperature range of measurement is between -20degree and 120degree. Displayer tells directly viscosity, rotary speed, temperature, centesimal torsion, serial number of the spindle and maxim viscosity that can be measured at present rotary speed of the spindle used. RS232 interface printing, the interval of which can be set by users themselves. Master control board and (). The circuit is designed by the most advanced microcomputer processor in the world, thus the structure is reasonable and compact. The full scale and levels of lineal measure are measured and adjusted through a PC interface, whose measuring capability is up to the advanced standards of similar types abroad.
Accessories Available: ULA, Small Sample Adapter, Standard Oil, Printer, Viscometer Dedicated Constant Temperature Flume, Remote Controller, Thermosel, SNB data collection and graphing software.
| Measuring range cp ((mPa·s)and Function | ||
| Adaptor | 0 rotor measuring range to 0.1mPa·s | |
| Small Sample Adapter | Small Sample 4--18ml Shearing Rate,shear stress data | |
| printer | s | |
| Standard Oil | 200 mPa·s---160000 mPa·s Capacty 400ml | |
| RTDTemperature Probe | Temperature Range-20ºC-120ºC | |
| Heater | Temperature Range(RT+10ºC+250ºC) Accuracy 0.1ºC | |
| Viscometer Dedicated Constant Temperature Flume 1 | -5ºCto+95ºC Stability:±0.05ºC,Resolution:0.1ºC put 1 pc of sample cup Capacity:6L | |
| Viscometer Dedicated Constant Temperature Flume 2 | -5ºC to +95ºC Stability:±0.05ºC,Resolution:0.1ºC,put three pc of sample cups,Capacity:15 | |
| STM-2 Sam Totman | 40KU-141KU,27cp-5274cp,32gm-1099gm | |
| DVprogram loading software | The program control to download on DV viscometer, operation under offline | |
| SNB data collection and graphing software | automatically date collection 2. viscosity curve, data memo function.3. Support comparison of history date for 10times 4. output Excel format's document | |
| DV data collection and Analysis software of program-controlling | 1. data collection, and fully automatical for controlling measure 2. getting viscosity curve ,data memo function3. Support comparison of history date for 10times 4. output Excel format's document 5. Operation offline6. to Analysize data, finishing graphing and print. |
